All stock codes associated to this product
SRT6KRMXLICSIL5YR, SRT6KRMXLI-CSIL-5YR, 2903506
|
10/100 BaseT Connection |
|
Connect the device to a
network using a 10 or 100 BaseT connection |
|
Battery failure notification |
|
Provides early-warning
fault analysis on batteries enabling timely preventive
maintenance |
|
Green mode |
|
Patent-pending
operating mode that bypasses unused electrical components in good power
conditions to achieve very high operating efficiency without sacrificing
any protection. |
|
LCD graphics display |
|
Text and mimic diagrams
that display modes of operation, system parameters and
alarms. |
|
Specification
|
Output |
|
Output power capacity |
|
6.0 KWatts / 6.0
kVA |
|
Max Configurable Power (Watts) |
|
6.0 KWatts / 6.0
kVA |
|
Nominal Output Voltage |
|
230V |
|
Output Voltage Distortion |
|
Less than
2% |
|
Output Frequency (sync to mains) |
|
50/60Hz +/- 3
Hz |
|
Other Output Voltages |
|
220,
240 |
|
Load Crest Factor |
|
3:01 |
|
Topology |
|
Double Conversion
Online |
|
Waveform type |
|
Sine
wave |
|
Output Connections |
|
(6) IEC 320 C13
(Battery Backup) |
|
(4) IEC 320 C19
(Battery Backup) |
|
Bypass |
|
Internal Bypass
(Automatic and Manual) |
|
Input |
|
Nominal Input Voltage |
|
230V |
|
Input frequency |
|
40 - 70 Hz (auto
sensing) |
|
Input Connections |
|
Hard Wire 3 wire
(1PH+N+G) |
|
Input voltage range for main operations |
|
160 - 275
V |
|
Input voltage adjustable range for mains
operation |
|
100 - 275 (half load)
V |
|
Other Input Voltages |
|
220,
240 |
|
Batteries &
Runtime |
|
Battery type |
|
Maintenance-free sealed
Lead-Acid battery with suspended electrolyte :
leakproof |
|
Typical recharge time |
|
1.5
hour(s) |
|
Replacement Battery |
|
APCRBC140 |
|
RBC Quantity |
|
1 |
|
Extendable Run Time |
|
1 |
|
Battery Volt-Amp-Hour Capacity |
|
902 |
|
Extended Run Options |
|
APC-Smart-UPS-SRT-6000VA-230V |
|
Runtime |
|
View Runtime
Graph |
|
View Runtime
Chart |
|
Efficiency |
|
View Efficiency
Graph |
|
Communications &
Management |
|
Interface Port(s) |
|
RJ-45 10/100 Base-T
, RJ-45 Serial , Smart-Slot , USB |
|
Control panel |
|
Multi-function LCD
status and control console |
|
Audible Alarm |
|
Audible and visible
alarms prioritized by severity |
|
Emergency Power Off (EPO) |
|
Yes |
|
Available SmartSlot Interface Quantity |
|
1 |
|
Surge Protection and
Filtering |
|
Surge energy rating |
|
480
Joules |
|
Physical |
|
Maximum Height |
|
432 mm , 43.2
cm |
|
Maximum Width |
|
174 mm , 17.4
cm |
|
Maximum Depth |
|
719 mm , 71.94
cm |
|
Net Weight |
|
60.0
kg |
|
Shipping weight |
|
67.0
kg |
|
Shipping Height |
|
370 mm , 37.0
cm |
|
Shipping Width |
|
610 mm , 61.0
cm |
|
Shipping Depth |
|
960 mm , 96.0
cm |
|
Color |
|
Black |
|
Units per Pallet |
|
6 |
|
Environmental |
|
Operating Environment |
|
0 - 40
C |
|
Operating Relative Humidity |
|
0 - 95% no
% |
|
Operating Elevation |
|
0-3000
meters |
|
Storage Temperature |
|
-15 - 45
C |
|
Storage Relative Humidity |
|
0 - 95% no
% |
|
Storage Elevation |
|
0-15000
meters |
|
Audible noise at 1 meter from surface of unit |
|
55.0
dBA |
|
Online thermal dissipation |
|
1300.0
BTU/hr |
|
Protection Class |
|
IP
20 |
|
