Overview
EXPERIENCE UNCOMPROMISED DISPLAY QUALITY
LG IPS monitors deliver all-around quality, colors, picture quality and wide
viewing angles. The technology was developed to address limitations in these
areas among standard LED screens.
- Original color reproduction
- Easier to carry out color-related jobs without color distortions
- Clear picture quality from any angle: Work in any position thanks to a
wide view
- Less Eye fatigue: Work longer hours without after-image
|
MANAGE
CONTENTS FOR EXIBLE AND RELIABLE CLOUD SOLUTION
eZ-CMS is the management software developed exclusively for LG Cloud T
Series.
- Self-diagnosis and help-desk functions
- Dashboard for an instant grasp of the system and faster performance
- Wizard for exact measurement of work scope and level
- Dynamic Grouping for easy grouping
SEEK UNLIMITED PERFORMANCE |
Citrix HDX Technology built for industrys highest performance video engine
enables a near-zero latency, life-like communication experience for multi-user
HD conferencing based on highly integrated Digital Media Processors, TI.
- HDX MediaStream: Highest performance video engine nearly zero latency
- HDX WAN Optimization: Performance and bandwidth optimizations for branch
offices
- HDX Plug-n-Play: Access to local resources and peripherals
- HDX SmartAccess: Simplified secure access
|
ACCESS SUFFICIENT WORK EFFICIENCY |
LG Cloud T series is ergonomically designed to offer more space
efficiency.
- Ergonomic design: User-compatible side interface and easy set-up &
cabling
- USB2.0: Six USB 2.0 ports enable accessories for enhanced functionality
- Built in Speaker: No more need for extra speakers to set up around your
monitor
- UPoE Ready: Reduction of operational cost and power consumption
Key Features
IPS The Premium Display
Lifelike Color
Wide Viewing Angle
Smooth Color Change
Texas Instruments
Citrix Ready-HDX Verified
HDX
Tilt
Pivot 90
Pivot
USB 2.0 (x6)
Built-in Speaker
UPOE Ready
EPEAT Silver
ENERGY STAR
Specifications
|
PANEL
|
|
|
TAA
Complaint |
Yes |
|
Panel Size (measured
diagonally) |
23"
(23.0") |
|
Processor |
TI DM8148 1GHz (750MHz
DSP included) |
|
RAM |
1GB
(DDR3-800) |
|
Protocol |
Citrix ICA with
HDX |
|
Ethernet |
Gigabit
Ethernet |
|
Color
Depth |
16.7M |
|
Pixel
Pitch(mm) |
0.2652(H)0.2652(V) |
|
Brightness
(Typ) |
250
cd/m2 |
|
Contrast
Ratio |
1,000:1(Typ)
5,000,000:1(DFC) |
|
Response Time
(on/off) |
14ms |
|
Viewing Angle
(CR10) |
178/178 |
|
Surface
Treatment |
Non-Glare |
|
Aspect
Ratio |
16:09 |
|
Panel
Type |
IPS |
|
Resolution |
1920 x
1080 |
|
|
|
INPUT (SIGNAL)
|
|
|
D-Sub |
Yes |
|
|
|
OUTPUT (SIGNAL)
|
|
|
DVI |
Yes (DVI-D, Span,
Mirror) |
|
D-Sub |
No |
|
|
|
INTERACTIVE
|
|
|
USB |
6 (USB2.0); 4 Back, 2
Side |
|
|
|
INPUT AUDIO
|
|
|
Mic
In |
Yes |
|
|
|
OUTPUT AUDIO
|
|
|
Headphone
Out |
Yes |
|
|
|
SPECIAL FEATURES
|
|
|
Built-in
Speaker |
1W x
2 |
|
4:3 in
Wide |
Yes |
|
Intelligent
Auto |
Yes |
|
Plug &
Play |
DDC2AB: RGB
Input |
|
|
|
CABINET
|
|
|
Color |
Black
Hairline |
|
Set (with Stand)
(WxHxD) |
21.4 x 15.2 (+5.1) x
8.9 |
|
Set (with Stand)
Weight |
12.3
Ibs. |
|
Set (without Stand)
(WxHxD) |
21.4" x 13.1" x
1.9" |
|
Set (without Stand)
Weight |
7.4
Ibs. |
|
Box
(WxHxD) |
24.3 x 15.9 x
7.8 |
|
Box
Weight |
16.2
Ibs. |
|
VESA Standard Mount
Interface |
100mm x
100mm |
|
Stand |
Base detachable, Tilt
(Yes / -5 (front) ~15 (rear)), Swivel (90), Height (130mm),
Pivot |
|
|
|
STANDARD
CERTIFICATION |
|
|
UL(cUL) |
Yes |
|
TUV-Type |
Yes |
|
FCC-B,
CE |
Yes |
|
EPA |
Yes |
|
EPEAT
(Silver) |
Yes |
|
|
|
POWER
|
|
|
Type |
Adapter (19V
DC) |
|
Input |
100-240V |
|
Normal On
(Typ) |
24W(Mon)/31W(Cloud) |
|
Power Save/Sleep Mode
(Max) |
0.5W(Monitor) /
8.5W(Cloud) |
|
DC Off
(Max) |
0.5W(Monitor)/
0.5W(Cloud) |
|
|
|
FREQUENCY
|
|
|
H-Frequency
(Analog) |
30 kHz ~ 68
kHz |
|
V-Frequency
(Digital) |
57Hz
~63Hz |
|
|
|
RESOLUTION
|
|
|
D-SUB
In |
1920 X
1080(Max) |
|
DVI
Out |
1920 X
1200(Max) |
|
|
|
WARRANTY
|
|
|
Warranty |
3-Year Limited Warranty
(Parts/Labor/Backlight) |
|
|
|
UPC
|
|
|
23CAT42K-B |
7 19192 19249
2 |
|
|
|
ACCESSORIES
|
|
|
D-Sub |
Yes |
|
Power
Cord |
Yes |
