General |
|
|
Topology |
Online, double-conversion |
|
Configuration |
Tower |
|
Part Number |
103007848-6591 (Marine Filter and Installation Kit are required for
the DNV and ABS compliance) |
|
Color |
Black |
|
Rating (VA/Watts) |
3000/2700 |
|
Diagnostics |
Full system
self-test |
|
UPS Bypass |
Automatic bypass |
|
Dimensions (H x W x
D, mm) |
469 x 392 x
445 |
|
Weight (kg) |
33 |
|
Remote Emergency
Power off (REPO) |
Emergency shutdown
control through the REPO port |
|
Efficiency |
94% in high-efficiency mode; 90% in online
mode |
|
|
|
Electrical
Input |
|
|
Connection |
(1) IEC-320-C20 |
|
Input Voltage
Range |
180-276 Vac (with load
PF of 0.7) |
|
Nominal Voltage |
220240V |
|
Frequency |
50/60
Hz |
|
Frequency Range |
4565 Hz |
|
Nominal
Current |
13.0A
@230V |
|
Breaker Ratings |
16A |
|
|
|
Battery |
|
|
Battery Description |
VRLA 12V/9 Ah (internal and
External) |
|
Battery
Type |
Replaceable maintenance
free sealed lead acid |
|
Battery Replacement |
Hot-swappable internal batteries |
|
Start On
Battery |
Allows start of UPS
without utility input |
|
|
|
Communications |
|
|
User Interface |
Graphical LCD with blue backlight and text in English, French,
German, Russian and Spanish |
|
LEDs |
Four status-indicating
LEDs |
|
Communication Ports |
RS-232 and USB HID port as
standard |
|
Relay
Output |
Common alarm
standard |
|
Communications Card Slots |
Optional SNMP/Web card for monitoring in SNMP-based networks,
monitoring through Web browser interface. Relay card for integration to
industrial environment and BMS, remote shutdown for IBM AS/400
systems |
|
|
|
Environmental &
Standards |
|
|
Heat Dissipation (BTU) |
Line: 1257, Bat: 1755 |
|
Audible
Noise |
<44
dB |
|
Operating Temperature |
0C to +40C |
|
Performance - Safety
- EMC |
CE (per IEC/EN62040-2:
Emissions, Category C1; Immunity, Category C2), GS, IEC/EN
60945 |
|
Storage Temperature |
-20C to +40C with batteries and -25C to +55C without
batteries |
|
Relative
Humidity |
590%
non-condensing |
|
OPTIONS |
|
|
Batteries |
|
|
Option |
Part
Number |
|
Eaton 9130 3000
Tower EBM |
103006440-6591 |
|
Extended Battery
Module (EBM) giving additional runtime for Eaton 9130 2000 and 3000 Tower
UPSs - up to 4 EBMs can be attached to each UPS |
|
Power Management
Connectivity |
|
|
Option |
Part
Number |
|
Network
Card-MS |
Network-MS |
|
Provides real time
monitoring and control across UPSs in your
network |
|
Network
and MODBUS Card-MS |
MODBUS-MS |
|
Provides continuous,
reliable and accurate remote monitoring of UPS
systems |
