IMG 1 of 1
No Longer Available

Part Number:
412197
(?) Brand:
Manuf No:
POW-4830
POW4830
Shipping Weight:
1.5 KG (Includes product packaging)
Estimate Shipping
Date Added:
All stock codes associated to this product
POW4830, POW-4830, 3269300, 4015867183625

Overview

The POW-4830 is a DIN-rail industrial power supply is ruggedized, universal input voltage range and full compliance with all important safety and EMC standards. It can be operated at full load across an ambient temperature range of -10 to 60 Celsius degree without need of additional cooling to guarantee quality for harsh industrial environment. Moreover, this power unit has been designed specifically for use with Infinity Industrial PoE Ethernet series, also it meets the requirements for both PoE and PoE Plus as well

Features

  • 12-36VDC Input
  • Short Circuit, Overload / Over Voltage Protection
  • Fanless Design
  • Supports DIN-rail installation
  • 100% Full Load Burn-in Test
  • DC to DC Power Converter
  • UL508 approval



Specifications

Output DC                             48V



Output Current                     1.78A



Output Power                       85W



Input Voltage                        12-36VDC



MTBF                                      34.4 years



Dimension & Weight            50 x 148 x 165mm @ 1.2kg



Operation Temperature       -10 to 60 Celsius



Operation Humidity             0 to 95% RH Non-condensing



Safety Approval                    EC60068, EN60950-1, UL60950-1, EN55011,

                                                EN55022 (CISPR22) Class B, EN61000-3-2,

                                                EN61000-3-3, EN61000-4-2/3/4/5/6/8/11,

                                                EN61000-6-2, EN61204, EN55024









No additional files, specification sheets, guides or documentation found for product.

Warranty: 12 Month Return To Base

Full manufacturers warranty details are available at the manufacturers web site.
