Printing
Method |
Monochrome Laser Beam
Printing |
Fixing
Method |
On Demand
Fixing |
Print
Speed |
Simplex: A4: up to 40
ppm (pages per minute) |
|
A3: up to 20 ppm (pages
per minute) |
|
Duplex: A4: up to 40
ppm (pages per minute) |
Print
Resolution |
600 x 600 dpi
equivalent (1200 Equivalent x 1200 dpi quality with Image Refinement
Technology) |
Warm-up
Time |
From Power On: 29 sec
or less |
|
From Quick Start: 17
sec or less |
Recovery Time (from
Sleep Mode) |
Panel Off: Approx. 0
sec |
|
Deep Sleep: 10 sec or
less |
First Print Out
Time |
Approx. 9.3
sec |
Print
Language |
UFRII, PCL5e/6,
PostScript 3, PDF, XPS |
Standard
Fonts |
PCL: 93
fonts |
|
PS/PDF: 136
fonts |
Auto Duplex
Print |
Standard |
Available Paper Size
for Auto Duplex Print |
A3, B4, A4, A4R, B5,
A5, Ledger, LTR, LTR-R, Legal2, Exe |
Print
Margins |
5mm-top, bottom, left
and right (Envelope: 10mm) |
Direct
Print |
TIFF, JPEG, PDF, XPS
(via USB Host 2.0) |
Paper
Input |
Standard Cassette:
60-84g/m2: 250-sheets |
|
Multi-Purpose Tray:
60-84g/m2: 100-sheets |
|
Optional: 60-74g/m2):
550 sheets |
Maximum Paper Input
Capacity |
2,000 sheets (Based on
60-74g/m2) |
Paper
Sizes |
Standard: A3, B4, A4,
A4R, B5, A5, Ledger, LTR-R, Legal2, Exe, foolscap, 8K, 16K, Custom
Size available3 |
|
Multi-Purpose Tray: A3,
B4, A4, A4R, B5, A5, Ledger, LTR, LTR-R, Legal2, Exe, STMT, foolscap,
8K, 16K, Custom Media: 76.2-312.0mm x
127.0-470.0mm |
|
Optional Paper Feeder
PF-A1: A3, B4, A4, A4R, B5, A59 Ledger, LTR, LTR-R, Legal2, Exe,
STMT, foolscap, 8K, 16K, Custom Size available3 |
Paper
Types |
Plain, Heavy, Recycled,
Colour, Transparency, Label, Envelope |
Paper
Weight |
Standard:
60120g/m2 |
|
Multi-Purpose Tray:
60199g/m2 |
|
Optional Paper Feeder
PF-A1: 60120g/m2 |
Paper
Output |
250 sheets (face
down) |
|
50 sheets (face
up) |
Standard
Interface(s) |
USB 2.0 High Speed, USB
2.0 Host (2 ports), 10/100 Base-T/1000 Base-T
Ethernet |
Expansion
Interface |
SD Card
Slot |
Operating System
Compatibility |
Windows XP
(32bit/64bit), Windows Vista (32bit/64bit), Windows 7 (32bit/64bit),
Windows 8 (32bit/64bit), Windows Server 2003 (32bit/64bit), Windows
Server 2008 (32bit/64bit), Windows Server 2008 R2 (64bit),
Windows Server 2012 (64bit), Mac OS 10.610.8.x4, Linux5,
Citrix |
Security
Function |
IPSec,
IEEE802.1x, |
|
Secure Print (with
optional SD Card) |
Support |
MEAP
function |
Mobile
Print |
Canon Mobile
Printing |
Memory |
768MB |
LCD
Display |
5-line
LCD |
Dimensions (W x D x
H) |
514 x 532 x
303mm |
Weight |
Approx. 25.8kg (without
cartridge) |
Power
Consumption |
Maximum:
1420W |
|
During Operation:
Approx. 670W (Average) |
|
During Standby: Approx.
38W (Average) |
|
During Sleep 1: Approx.
38W |
|
During Sleep 2: Approx.
12W |
|
During Sleep 3: Approx.
1.1W |
Energy Star TEC
(Typical Electricity Consumption) |
2.2kWh/week |
Noise
Level |
During Operation: Sound
Power Level: 7.30B or less Sound Pressure Level :
56dB |
|
During Standby: Sound
Power Level: Inaudible Sound Pressure Level:
Inaudible |
Operating
Environment |
Temperature: 1030C,
Humidity: 2080%RH (no condensation) |
Power
Requirements |
AC 220V-240,
50/60Hz |
Toner
Cartridge |
Cartridge 333: 10,000
pages |
|
Cartridge 333 H: 17,000
pages |
Monthly Duty
Cycle |
Up to 65,000
pages |
Optional
Accessories |
Paper Feeder PF-A1
(550-sheets), Barcode Printing Kit-F1, Canon SD Card-B1 (8GB),
Universal Cassette UC-A18 |
