Technology |
|
|
Printer
Type |
5 Colour -
36"/914.4mm |
|
Print
Technology |
Canon Bubblejet on
Demand 6 colours integrated type (6 chips per print head x 1 print
head) |
|
Number of
Nozzles |
Total: 15,360 MBK:
5,120 nozzles |
|
C, M, Y, BK: 2,560
nozzles each |
|
Print
Resolution |
2,400 x 1,200
dpi |
|
Nozzle
Pitch |
1,200 x 2 includes
Non-firing nozzle detection and compensation system |
|
Line
Accuracy |
0.1 % or
less |
|
Ink Droplet
Size |
5 Picolitre per
colour |
|
Ink
Capacity |
Bundled Starter Ink:
330ml (MBK)/160ml (BK,C,M,Y) |
|
Sales Ink:
160ml/330ml/700ml |
|
Ink
Type |
Pigment ink: 5
colourMBK/BK/C/M/Y |
|
OS
Compatability |
Microsoft Windows 32
Bit: 7, 8.1, 10, Server 2008, 64 Bit: 7, 8.1, 10, Server 2008/ R2, Server
2012/R2 |
|
Apple Macintosh: OSX
10.10.5 ~ 10.11, MacOS 10.12 |
|
Printer
languages |
HP-GL/2, HP RTL, PDF,
JPEG - for details check specifications |
|
Standard
Interfaces |
|
CHANGE: |
|
USB B
Port: |
|
Type: Built in
(Hi-Speed USB) |
|
Mode: Full Speed (12
Mbit/sec), High Speed (480 Mbit/sec), Bulk transfer |
|
Connector Port: Series
B (4 pins) |
|
USB A Port: USB Memory
(Direct Print |
|
Standard: |
|
IEEE 802.3
10base-T |
|
IEEE 802.3u
100base-TX/Auto-Negotiation |
|
IEEE 802.3ab
1000base-T/Auto-Negotiation |
|
IEEE 802.3x Full
Duplex |
|
Protocol: |
|
SNMP (Canon-MIB, HTTP,
TCP/IP (IPv4/IPv6), ftp |
|
Wireless
LAN: |
|
Standard: |
|
IEEE802.11n/IEEE802.11g/IEEE802.11b |
|
Security: |
|
WEP
(64/128bit) |
|
WPA-PSK
(TKIP/AES) |
|
WPA2-PSK
(TKIP/AES) |
|
MEMORY |
|
|
Standard
Memory |
128GB (Physical memory
2GB) |
|
Expansion
slot |
No |
|
Printing
Speed |
CAD
Drawing |
|
Plain Paper (A0
Roll) |
|
0:37 (Fast Economy
Mode) |
|
0:40
(Fast) |
|
1:10
(Standard) |
|
Poster |
|
Plain Paper (A0
Roll) |
|
0:42 (Fast Economy
mode) |
|
0:42
(Fast) |
|
1:26
(Standard) |
|
Heavy coated Paper (A0
Roll) |
|
1:43
(Fast) |
|
2:37
(Standard) |
|
HARD
DISK |
500GB
(Encrypted) |
|
Paper
Handling |
|
|
Media
Width |
Roll paper: 203.2mm -
917mm |
|
Cut sheet: 203.2mm -
917mm |
|
Media
thickness |
0.07 -
0.8mm |
|
Minimum Printable
Length |
203.2mm |
|
Maximum Printable
Length |
Roll paper: 18m (varies
according to the OS and application) |
|
Cut sheet:
1.6m |
|
Maximum Media Roll
Diameter |
170mm |
|
Paper Feed
Method |
Roll Paper: Front
loading, front output |
|
Cut Sheet: Front
loading, front output |
|
(Manual feed using
media locking lever) |
|
Borderless Printing
Width (Roll Only) |
[Recommend] 515mm(JIS
B2), 728mm(JIS B1), 594mm(ISO A1), 841mm(ISO A0), 10", 14", 17", 24",
36" |
|
[Printable] 257mm(JIS
B4), 297mm(ISO A3), 329mm(ISO A3+), 420mm(ISO A2), 8", 12", 16, 20", 30",
300mm, 500mm, 600mm, 800mm |
|
Maximum Numbers of
delivered prints Multi-position Basket |
Standard Position : 1
sheet (any image) |
|
Flat Position : 20
sheets (A2 landscape, any image, plain paper/coated
paper) |
|
Maximum Numbers of
delivered prints Stacker |
Basket Position : 1
sheet (any image) |
|
Folding Position : 100
sheets (A0/A1 portrait, CAD drawing, plain paper) |
|
Stacking Position : 100
sheets (A1/A2 landscape, CAD drawing, plain paper) |
|
DIMENSIONS AND
WEIGHT |
|
|
Physical Dimensions and
Weight |
Printer unit with
basket open and printer stand: |
|
1389 x 984 x 1168 mm
(Basket Open) |
|
Weight: 105 kg
(including Roll Holder) |
|
Software
Included |
imagePROGRAF TX-Series
Printer Driver, Quick Utility Toolbox, Print Plug-in for Office, Extended
Survey Program and Poster Artist Lite other software is available to
download from Canons web site. |
|
Power and operating
requirements |
|
|
Power
Supply |
Input Power: AC 100-240
V (50-60 Hz) |
|
Power
Consumption |
Power consumption
(using wired LAN): 105 W or less |
|
At sleep mode (using
wired LAN): 3.6 W or less |
|
At sleep mode (using
all ports): 3.6 W or less |
|
EU only - data for ErP
Lot 26 |
|
At the power off: 0.3 W
or less |
|
Default setting for the
time to enter the Sleep mode: 301sec |
|
Operating
Environment |
15 - 30C, 10 - 80
% (Condensation
free) |
|
Noise
Level |
Operation : 51dB(A) or
less (Plain paper, line drawing, standard mode) |
|
Stand by : 35dB(A) or
less |
|
(Measured on ISO7779
standard) |
|
Regulations |
Europe: CE, Russia:
EAC |
|
Certificates |
ENERGY STAR (WW), TUV,
CB |
|
WHAT'S
INCLUDED |
|
|
What's in the
box? |
Printer, Roll Unit, 1 x
Print Head, 1 x Maintenance Cartridge, 3 Paper Core Attachment, EU &
UK Power Cable, 1 Set of Starter Ink Tanks, Set Up Guide, Safety/Standard,
Software CD-ROM (OSX/Windows), PosterArtist Lite CD-ROM, EU Biocide Sheet,
Eurasian Economic Union Sheet, Important Information Sheet, Quick Guide
and Print head Alignment Sheet |
|
Options |
|
|
Optional
Items |
Roll Unit:
RU-32 |
|
Stacker:
SS-31 |
|
2/3" Roll Holder:
RH2-34 |
|
Consumables |
|
|
User Replaceable
Items |
Print Head:
PF-06 |
|
Ink Tanks:
PFI-110(160ml), PFI-310(330ml), PFI-710(700ml) |
|
Cutter Blade:
CT-07 |
|
Maintenance Cartridge:
MC-30 |
