Dimensions |
W: 210mm H: 435mm D:
428mm (without feet) |
W: 210mm H: 460mm D:
428mm (with feet) |
Material(s) |
SGCC Steel, Tempered
Glass |
Weight |
7.5
kg |
Clearance |
Cable Management:
19-23mm |
GPU Clearance: Up to
368.6mm w/o front radiator installed, up to 313.6mm with front radiator
installed |
Vertical GPU Mount
Clearance: 40.64mm |
CPU Cooler: Up to
165mm |
Front Radiator:
60mm |
Rear Radiator:
60mm |
Reservoir & Pump:
Up to 180mm (Along cable bar), Up to 86mm (Along bottom
panel) |
Motherboard
Support |
Mini-ITX, MicroATX,
ATX |
Front I/O
Ports |
1x USB 3.1 Gen 2
Type-C |
1x USB 3.1 Gen 1
Type-A |
1x Headset Audio
Jack |
Front I/O internal
header |
1x USB 3.1 Gen 2
Internal Header |
1x USB 3.1 Gen 1
Internal Header |
1x USB 2.0 Internal
Header |
1x HD Audio
Header |
Filters |
All Air
Intakes |
Smart Device
V2 |
3x Fan channels with
Max 10W per channel output* |
2x RGB LED channels,
each support up to 4x HUE 2 addressable LED strips or 5x Aer RGB 2
fans |
Built-in noise
detection module |
*Note : If a
splitter is used, fan control is regulated depending on the fan connected
to the 4-pin port . Do not use low-noise
adapters. |
RGB LED
Lighting |
2x Integrated Aer RGB 2
140mm Fans |
1x Integrated
addressable LED Strip |
Vertical GPU
Mount |
2
Slots |
Drive
Bays |
2.5":
2+1 |
3.5":
2+1 |
Expansion
Slots |
7 |
Radiator
Support |
Front: 2x 140 or 2x
120mm with Pull |
*Note: Need to
remove RGB fans if you plan to mount the radiator to the
front |
Rear: 1x
120mm |
Fan
Support |
Front: 2x 120/ 2x 140mm
(2x AER RGB 2 140mm included) |
Top: 1x 120mm/ 1x 140mm
(1x AER F140 Case Version Included) |
Rear: 1x 120mm (1x AER
F120 Case Version Included) |
Fan
Specs |
Aer RGB 2
(140mm) |
Speed: 500-1,500
RPM |
Airflow: 30.39 - 91.19
CFM |
Noise: 22 - 33
dBA |
Air Pressure: 0.17
1.52mm-H2O |
Bearing: Fluid Dynamic
Bearing |
Fan Connector 4-Pin
PWM |
Warranty |
2
Years |
Model
Number |
CA-H510E-B1 |
EAN |
5060301695287 |
UPC |
815671015105 |
