Dimensions |
L:
150mm W: 150mm H: 86mm |
Material(s) |
Steel,
PCB and plastic |
Compliance
Standard |
ATX12V
v2.4 / EPS12V v2.92 |
PF
Correction |
[email protected] |
AC
Input Rating |
100-240Vac,
9-4.5A, 50-60Hz |
Fan
Specs |
Dimensions:
W: 120mm H: 120mm D: 25mm |
Speed:
0-2,200 + 220 RPM |
Airflow:
73.9 CFM |
Noise:
32.3 dBA |
Bearing:
FDB (Fluid Dynamic Bearing) |
Hazardous
Materials |
RoHS
& China RoHS |
Energy
Efficiency |
80
Plus Gold |
20%
loading: 87%, 50% loading: 90%, 100% loading: 87%
@115Vac |
Operation
Temperature |
0
to 50C |
Regulations
& Certifications (EMC & Safety) |
CB
/ CE / FCC / TUV / cTUV-SUDus / China CCC / Taiwan BSMI / Australia RCM /
EAC |
MTBF |
100,000
hours |
Output
Connector(s) |
1
x 24-pin ATX power |
2
x 4+4-pin CPU power |
4
x PCIe (6+2 pin) |
8
x SATA |
6
x Peripherals |
Included
Cables |
1
x 24-pin ATX power (length: 610 mm, Nylon
sleeving) |
2
x 4+4-pin CPU power (length: 650 mm, Nylon
sleeving) |
2
x PCIe (6+2 pin) (length: 675 +75 mm, Nylon
sleeving) |
2
x SATA (length: 500 + 100 +100 +100 mm) |
2
x Peripherals (length: 500 + 100 +100 mm) |
Warranty |
10
years |
Model
Number |
NP-C650M-US |
UPC |
815671015945 |
EAN |
5060301695775 |
