CPU |
Intel Socket
LGA1700 for 12th Gen Intel Core,
Pentium Gold and
Celeron Processors* |
|
Supports
Intel Turbo Boost Technology 2.0 and
Intel Turbo Boost Max Technology
3.0** |
|
*
Refer to www.asus.com for CPU support
list. |
|
**
Intel Turbo Boost Max Technology 3.0 support depends on
the CPU types. |
|
Chipset |
Intel H610
Chipset |
|
Memory |
2
x DIMM, Max. 64GB, DDR4 3200/3000/2933/2800/2666/2400/2133 Non-ECC,
Un-buffered Memory* |
|
Dual
Channel Memory Architecture |
|
Supports
Intel Extreme Memory Profile
(XMP) |
|
*
Actual memory data rate depends on the CPU types and DRAM modules, for
more information refer to www.asus.com for memory support
list. |
|
Graphics |
1
x D-Sub port |
|
1
x HDMI port** |
|
*
Graphics specifications may vary between CPU types. Please refer to
www.intel.com for any updates. |
|
**
Supports 4K@60Hz as specified in HDMI 2.1. |
|
Expansion
Slots |
Intel 12th Gen
Processors |
|
1
x PCIe 4.0 x16 slot |
|
Intel H610
Chipset |
|
1
x PCIe 3.0 x1 slot |
|
Storage |
Total
supports 1 x M.2 slot and 4 x SATA 6Gb/s
ports |
|
Intel H610
Chipset |
|
M.2
slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA
modes) |
|
4
x SATA 6Gb/s ports |
|
*
The M.2 slot shares bandwidth with the SATA6G_4 port. When a device in
SATA mode is installed on the M.2 slot, the SATA6G_4 port cannot be
used. |
|
Ethernet |
1
x Realtek 1Gb Ethernet |
|
USB |
Rear
USB (Total 6 ports) |
|
2
x USB 3.2 Gen 1 ports (2 x Type-A) |
|
4
x USB 2.0 ports (4 x Type-A) |
|
Front
USB (Total 4 ports) |
|
1
x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1
ports |
|
1
x USB 2.0 header supports additional 2 USB 2.0
ports |
|
Audio |
Realtek
7.1 Surround Sound High Definition Audio
CODEC* |
|
-
Supports: Jack-detection, Multi-streaming, Front Panel
Jack-retasking |
|
-
Supports up to 24-Bit/192 kHz playback |
|
Audio
Features |
|
-
Audio Shielding |
|
-
Dedicated audio PCB layers |
|
*
A chassis with an HD audio module in the front panel is required to
support 7.1 Surround Sound audio output. |
|
Back
Panel I/O Ports |
2
x USB 3.2 Gen 1 ports (2 x Type-A) |
|
4
x USB 2.0 ports (4 x Type-A) |
|
1
x D-Sub port |
|
1
x HDMI port |
|
1
x Realtek 1Gb Ethernet port |
|
3
x Audio jacks |
|
1
x PS/2 Keyboard/Mouse combo port |
|
Internal
I/O Connectors |
Fan
and Cooling related |
|
1
x 4-pin CPU Fan header |
|
1
x 4-pin Chassis Fan header |
|
Power
related |
|
1
x 24-pin Main Power connector |
|
1
x 8-pin +12V Power connector |
|
Storage
related |
|
1
x M.2 slot (Key M) |
|
4
x SATA 6Gb/s ports |
|
USB |
|
1
x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1
ports |
|
1
x USB 2.0 header supports additional 2 USB 2.0
ports |
|
Miscellaneous |
|
1
x RGB header |
|
1
x Clear CMOS header |
|
1
x COM Port header |
|
1
x Front Panel Audio header (AAFP) |
|
1
x S/PDIF Out header |
|
1
x Speaker header |
|
1
x SPI TPM header (14-1pin) |
|
1
x 10-1 pin System Panel header |
|
Special
Features |
ASUS
5X PROTECTION III |
|
-
DIGI+ VRM |
|
-
LANGuard |
|
-
Overvoltage Protection |
|
-
SafeSlot Core |
|
-
Stainless-Steel Back I/O |
|
ASUS
Q-Design |
|
-
Q-DIMM |
|
-
Q-Slot |
|
ASUS
Thermal Solution |
|
-
Aluminum heatsink design |
|
ASUS
Lighting Control |
|
-
RGB header |
|
Software
Features |
ASUS
Exclusive Software |
|
Armoury
Crate |
|
AI
Suite 3 |
|
-
Performance And Power Saving Utility |
|
TurboV
EVO |
|
EPU |
|
DIGI+
VRM |
|
Fan
Xpert |
|
ASUS
CPU-Z |
|
Norton
Anti-virus software (Free Trial version) |
|
WinRAR |
|
UEFI
BIOS |
|
ASUS
EZ DIY |
|
-
ASUS CrashFree BIOS 3 |
|
-
ASUS EZ Flash 3 |
|
-
ASUS UEFI BIOS EZ Mode |
|
BIOS |
128
Mb Flash ROM, UEFI AMI BIOS |
|
Manageability |
WOL
by PME, PXE |
|
Accessories |
Cables |
|
2
x SATA 6Gb/s cables |
|
Miscellaneous |
|
1
x I/O Shield |
|
1
x M.2 ANCHOR |
|
Installation
Media |
|
1
x Support DVD |
|
Documentation |
|
1
x User Guide |
|
Operating
System |
Windows 11
64-bit, Windows 10 64-bit |
|
Form
Factor |
mATX
Form Factor |
|
9.2
inch x 8.0 inch ( 23.4 cm x 20.3 cm
) |
