| Processor |
|---|
| Processor cache | 24 MB |
| Processor frequency | 2.4 GHz |
| Processor family | Intel Xeon Silver |
| Processor model | 4314 |
| Processor boost frequency | 3.4 GHz |
| Processor manufacturer | Intel |
| Memory |
|---|
| Internal memory | 32 GB |
| Maximum internal memory | 2000 GB |
| Internal memory type | DDR4-SDRAM |
| Memory slots | 32x DIMM |
| Memory layout (slots x size) | 1 x 32 GB |
| Memory clock speed | 3200 MHz |
| ECC | Yes |
| Storage |
|---|
| RAID support | Yes |
| RAID levels | 0, 1, 5, 10 |
| Optical drive type | No |
| Number of HDDs supported | 8 |
| Maximum storage capacity | 153 TB |
| Network |
|---|
| LAN controller | Broadcom 57416 |
| Ethernet LAN | Yes |
| Ethernet interface type | 10 Gigabit Ethernet |
| Ports & interfaces |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 2.0 ports quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Design |
|---|
| Chassis type | Rack (1U) |
| Rack mounting | Yes |
| Optical drive type | No |
| Product colour | Silver |
| Performance |
|---|
| Compatible operating systems | Windows Server 2016: Essentials, Standard, Datacenter
Windows Server 2019: Essentials, Standard, Datacenter
Windows Server 2022: Essentials, Standard, Datacenter
Microsoft Hyper-V Server: 2016, 2019 & 2022
VMware vSphere: 6.7 U3 w /P03, 7.0 U2
Red Hat Enterprise Linux (RHEL): 7.9, 8.2 (64 bit, includes KVM)
SUSE Linux Enterprise Server (SLES): 12 SP5, 15 SP2 (64 bit, includes KVM & Xen)
Canonical Ubuntu: 20.04 LTS (64 bit)
Oracle Linux: 7.9, 8.2
Citrix: Hypervisor: 8.2 LTSR |
| Software |
|---|
| Compatible operating systems | Windows Server 2016: Essentials, Standard, Datacenter
Windows Server 2019: Essentials, Standard, Datacenter
Windows Server 2022: Essentials, Standard, Datacenter
Microsoft Hyper-V Server: 2016, 2019 & 2022
VMware vSphere: 6.7 U3 w /P03, 7.0 U2
Red Hat Enterprise Linux (RHEL): 7.9, 8.2 (64 bit, includes KVM)
SUSE Linux Enterprise Server (SLES): 12 SP5, 15 SP2 (64 bit, includes KVM & Xen)
Canonical Ubuntu: 20.04 LTS (64 bit)
Oracle Linux: 7.9, 8.2
Citrix: Hypervisor: 8.2 LTSR |
| Power |
|---|
| Redundant power supply (RPS) support | Yes |
| Number of redundant power supplies installed | 1 |
| Power supply | 800 W |
| Power supply input voltage | 200 - 240 V |
| Weight & dimensions |
|---|
| Width | 434.6 mm |
| Weight | 13.3 kg |
| Height | 42.9 mm |
| Depth | 741.9 mm |
