Performance |
---|
Windows operating systems supported | Windows 10, Windows 11, Windows 7, Windows 8, Windows 8.1 |
Linux operating systems supported | Kernel 2.6.31, Kernel 2.6.33, Kernel 3.12, Kernel 3.17, Kernel 3.3, Kernel 4.6.4, Linux Kernel 5.10, Linux Kernel 5.11, Linux Kernel 5.12, Linux Kernel 5.13, Linux Kernel 5.14, Linux Kernel 5.15, Linux Kernel 5.8, Linux Kernel 5.9 |
Interface | PCI Express 3.0 |
Component for | PC/Laptop |
SSD capacity | 500 GB |
Read speed | 3200 MB/s |
Write speed | 2000 MB/s |
NVMe | Yes |
NVMe version | 1.4 |
Memory type | 3D NAND |
PCI Express interface data lanes | x4 |
Random read (4KB) | 250000 IOPS |
Random write (4KB) | 170000 IOPS |
S.M.A.R.T. support | Yes |
ECC | Yes |
Hardware encryption | No |
Mean time between failures (MTBF) | 2000000 h |
TBW rating | 200 |
Features |
---|
Interface | PCI Express 3.0 |
Component for | PC/Laptop |
SSD capacity | 500 GB |
Read speed | 3200 MB/s |
Write speed | 2000 MB/s |
NVMe | Yes |
NVMe version | 1.4 |
Memory type | 3D NAND |
PCI Express interface data lanes | x4 |
Random read (4KB) | 250000 IOPS |
Random write (4KB) | 170000 IOPS |
S.M.A.R.T. support | Yes |
ECC | Yes |
Hardware encryption | No |
Mean time between failures (MTBF) | 2000000 h |
TBW rating | 200 |
Windows operating systems supported | Windows 10, Windows 11, Windows 7, Windows 8, Windows 8.1 |
Linux operating systems supported | Kernel 2.6.31, Kernel 2.6.33, Kernel 3.12, Kernel 3.17, Kernel 3.3, Kernel 4.6.4, Linux Kernel 5.10, Linux Kernel 5.11, Linux Kernel 5.12, Linux Kernel 5.13, Linux Kernel 5.14, Linux Kernel 5.15, Linux Kernel 5.8, Linux Kernel 5.9 |
Certification | CE, FCC, BSMI, KC, RCM, UKCA |
SSD form factor | M.2 |
M.2 SSD size | 2280 (22 x 80 mm) |
Power |
---|
Operating voltage | 3.3 V |
Design |
---|
Certification | CE, FCC, BSMI, KC, RCM, UKCA |
SSD form factor | M.2 |
Weight & dimensions |
---|
Width | 22 mm |
Depth | 80 mm |
Weight | 8 g |
System requirements |
---|
Windows operating systems supported | Windows 10, Windows 11, Windows 7, Windows 8, Windows 8.1 |
Linux operating systems supported | Kernel 2.6.31, Kernel 2.6.33, Kernel 3.12, Kernel 3.17, Kernel 3.3, Kernel 4.6.4, Linux Kernel 5.10, Linux Kernel 5.11, Linux Kernel 5.12, Linux Kernel 5.13, Linux Kernel 5.14, Linux Kernel 5.15, Linux Kernel 5.8, Linux Kernel 5.9 |
Operational conditions |
---|
Operating temperature (T-T) | 0 - 70 °C |
Technical details |
---|
Interface | PCI Express 3.0 |
Operating temperature (T-T) | 0 - 70 °C |
SSD form factor | M.2 |
Software |
---|
Windows operating systems supported | Windows 10, Windows 11, Windows 7, Windows 8, Windows 8.1 |
Linux operating systems supported | Kernel 2.6.31, Kernel 2.6.33, Kernel 3.12, Kernel 3.17, Kernel 3.3, Kernel 4.6.4, Linux Kernel 5.10, Linux Kernel 5.11, Linux Kernel 5.12, Linux Kernel 5.13, Linux Kernel 5.14, Linux Kernel 5.15, Linux Kernel 5.8, Linux Kernel 5.9 |
