| Performance |
|---|
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Indoor & outdoor |
| Thermal module | Yes |
| Design |
|---|
| IK code | IK10 |
| Form factor | Bullet |
| Product colour | Black, White |
| Mounting type | Wall |
| International Protection (IP) code | IP66, IP67 |
| Housing material | Aluminium, Polycarbonate (PC) |
| Camera |
|---|
| Camera pixel size | 17 µm |
| Lens viewing angle, horizontal | 55° |
| Lens viewing angle, vertical | 41° |
| Image sensor |
|---|
| Sensor type | Microbolometer |
| Effective sensor resolution (thermal module) | 384 x 288 pixels |
| Number of sensors | 1 |
| Lens system |
|---|
| Number of lenses | 1 |
| Maximum aperture number | 1.18 |
| Closest focusing distance | 12 m |
| Lens diameter | 7 mm |
| Video |
|---|
| Image quality adjustment | Brightness, Contrast, Sharpness |
| Text caption overlay | Yes |
| Flip & mirror | Yes |
| Image stabilizer | Yes |
| Gain control type | Auto |
| Bit rate control | Variable Bit Rate (VBR) |
| Maximum resolution | 768 x 576 pixels |
| Video formats supported | AVC, H.264, H.265, HEVC, M-JPEG |
| Frame rate | 30 fps |
| Video streaming | Yes |
| Audio |
|---|
| Audio system full duplex | Yes |
| Audio system | 2-way |
| Audio formats supported | AAC-LC, ADPCM, G.711, G.726, LPCM, OPUS, PCM |
| Audio detection | Yes |
| Network |
|---|
| Ethernet interface type | Fast Ethernet, Gigabit Ethernet |
| Networking standards | IEEE 802.1AE, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at |
| Streaming method | Multicast |
| Ethernet LAN | Yes |
| Supported network protocols | IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS , HTTP/2, TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP , SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, DHCPv4/v6, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf) |
| Storage |
|---|
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Flash memory | 8192 MB |
| RAM capacity | 2048 MB |
| Ports & interfaces |
|---|
| Terminal block port | Yes |
| Microphone in | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Yes |
| Connectivity technology | Wired |
| Security |
|---|
| Privacy protection | Yes |
| Alert notification type | E-mail |
| Video motion detection | Yes |
| Security algorithms | EAP-TLS, HTTPS, MSCHAPv2 |
| Active tampering alarm | Yes |
| Password protection | Yes |
| Pixel counter | Yes |
| Digest authentication | Yes |
| Management features |
|---|
| Cloud-managed | Yes |
| Power |
|---|
| Power source type | DC, PoE |
| Power consumption (Power over Ethernet (PoE)) | 12.95 W |
| Power consumption (typical) | 3.6 W |
| Power consumption (max) | 12.95 W |
| DC-in jack | Yes |
| Operational conditions |
|---|
| Operating temperature (T-T) | -40 - 60 °C |
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 10 - 100% |
| Storage relative humidity (H-H) | 5 - 95% |
| Weight & dimensions |
|---|
| Width | 132 mm |
| Depth | 272 mm |
| Height | 132 mm |
| Weight | 1.4 kg |
| Packaging content |
|---|
| Number of cameras | 1 |
| Technical details |
|---|
| Doesn't contain | CFR, Halogen, PVC/BFR |
| Other features |
|---|
| Doesn't contain | CFR, Halogen, PVC/BFR |
