Performance |
---|
Brand specific technologies | SLC Caching |
Windows operating systems supported | Windows 10, Windows 11, Windows 7, Windows 8, Windows 8.1 |
Linux operating systems supported | Kernel 2.6.31, Kernel 2.6.33, Kernel 3.12, Kernel 3.17, Kernel 3.3, Kernel 4.6.4, Linux Kernel 5.10, Linux Kernel 5.11, Linux Kernel 5.12, Linux Kernel 5.13, Linux Kernel 5.14, Linux Kernel 5.15, Linux Kernel 5.4, Linux Kernel 5.8, Linux Kernel 5.9 |
Interface | PCI Express 4.0 |
Component for | Laptop |
SSD capacity | 512 GB |
Read speed | 3300 MB/s |
Write speed | 1700 MB/s |
NVMe | Yes |
NVMe version | 1.4 |
Memory type | 3D NAND |
PCI Express interface data lanes | x4 |
Random read (4KB) | 119000 IOPS |
Random write (4KB) | 395000 IOPS |
S.M.A.R.T. support | Yes |
Hardware encryption | No |
Mean time between failures (MTBF) | 2000000 h |
TBW rating | 300 |
Features |
---|
Interface | PCI Express 4.0 |
Component for | Laptop |
SSD capacity | 512 GB |
Read speed | 3300 MB/s |
Write speed | 1700 MB/s |
NVMe | Yes |
NVMe version | 1.4 |
Memory type | 3D NAND |
PCI Express interface data lanes | x4 |
Random read (4KB) | 119000 IOPS |
Random write (4KB) | 395000 IOPS |
S.M.A.R.T. support | Yes |
Hardware encryption | No |
Mean time between failures (MTBF) | 2000000 h |
TBW rating | 300 |
Windows operating systems supported | Windows 10, Windows 11, Windows 7, Windows 8, Windows 8.1 |
Linux operating systems supported | Kernel 2.6.31, Kernel 2.6.33, Kernel 3.12, Kernel 3.17, Kernel 3.3, Kernel 4.6.4, Linux Kernel 5.10, Linux Kernel 5.11, Linux Kernel 5.12, Linux Kernel 5.13, Linux Kernel 5.14, Linux Kernel 5.15, Linux Kernel 5.4, Linux Kernel 5.8, Linux Kernel 5.9 |
Certification | CE/UKCA/FCC/BSMI/KC/RCM |
SSD form factor | M.2 |
M.2 SSD size | 2230 (22 x 30 mm) |
Drive writes per day (DWPD) | 0.33 |
Power |
---|
Operating voltage | 3.3 V |
Brand-specific features |
---|
Brand specific technologies | SLC Caching |
Design |
---|
Certification | CE/UKCA/FCC/BSMI/KC/RCM |
SSD form factor | M.2 |
Weight & dimensions |
---|
Width | 22 mm |
Depth | 30 mm |
Height | 2.23 mm |
Weight | 4 g |
System requirements |
---|
Windows operating systems supported | Windows 10, Windows 11, Windows 7, Windows 8, Windows 8.1 |
Linux operating systems supported | Kernel 2.6.31, Kernel 2.6.33, Kernel 3.12, Kernel 3.17, Kernel 3.3, Kernel 4.6.4, Linux Kernel 5.10, Linux Kernel 5.11, Linux Kernel 5.12, Linux Kernel 5.13, Linux Kernel 5.14, Linux Kernel 5.15, Linux Kernel 5.4, Linux Kernel 5.8, Linux Kernel 5.9 |
Operational conditions |
---|
Operating temperature (T-T) | 0 - 70 °C |
Technical details |
---|
Interface | PCI Express 4.0 |
Operating temperature (T-T) | 0 - 70 °C |
SSD form factor | M.2 |
Software |
---|
Windows operating systems supported | Windows 10, Windows 11, Windows 7, Windows 8, Windows 8.1 |
Linux operating systems supported | Kernel 2.6.31, Kernel 2.6.33, Kernel 3.12, Kernel 3.17, Kernel 3.3, Kernel 4.6.4, Linux Kernel 5.10, Linux Kernel 5.11, Linux Kernel 5.12, Linux Kernel 5.13, Linux Kernel 5.14, Linux Kernel 5.15, Linux Kernel 5.4, Linux Kernel 5.8, Linux Kernel 5.9 |
