All stock codes associated to this product
NFA14X25 G2 LSPWM, NF-A14X25 G2 LS-PWM
Next-gen 14cm design
For unprecedented quiet cooling performance
State-of-the-art engineering
Progressive Bend impeller, Sterrox LCP material & ultra tight tip clearance
4-pin, low-speed version
Ideal for semi-passive setups
Succeeding the award-winningNF-A14and building on the technological innovations of the ground-breakingNF-A12x25, the NF-A14x25 G2 is Noctuas next-generation square-frame 140mm flagship model: Made fromSterrox LCP, its highly optimisedProgressive-Bend impellerwith winglets,Flow Acceleration Channelsand Centrifugal Turbulator hub combined with a tip-clearance of only 0.7mm allow the NF-A14x25 G2 to further improve its predecessors renowned quiet cooling performance.
Like the NF-A14 and NF-A12x25, it is a true all-rounder that yields superb results in all types of usage, regardless of whether its in low-impedance, airflow-oriented applications such as case cooling, or high-impedance, static pressure demanding scenarios such as on heatsinks and water cooling radiators. For application-specific optimisation, the NF-A14x25 G2 comes with an NA-AVG2-LR anti-vibration gasket pre-installed to create a tighter seal on radiators. Additionally, its AAO (Advanced Acoustic Optimisation) frame can be combined with the optionalNA-IS1-14inlet spacer, which can help to achieve superior suction acoustics and flow rates in challenging intake configurations.
The 4-pin LS-PWM version is a low-speed, PWM-enabled variant that is ideal for semi-passive setups or ultra-low-noise applications that require near-silent acoustics and PWM based speed control. Its super-low-lossetaPERFmotor with Smooth Commutation Drive 2 technology combines unprecedented energy efficiency with a superb running smoothness that is guaranteed to satisfy even the most noise-sensitive users.
Topped off with Noctuas reference-classSSO2bearing, a rich bundle of accessories and 6-year manufacturers warranty, the NF-A14x25 G2 is a premium-quality product through and through. Its superior performance, comprehensive feature set, cutting-edge construction and state-of-the-art materials set a new standard within Noctuas portfolio and make it an elite choice for the most discerning demands.
Size (Form factor) | 140 x 140 x 25 mm (square) |
Speed range | |
Airflow (max.) | 81.6 m/h (48.03 CFM) |
Acoustical noise (max.) | 11.4 dB(A) |
Static pressure (max.) | 0.71 mm HO |
Rated voltage | 12 V |
Connector | 4-pin |
Colour | Brown |
Warranty | 6 years |
- NA-RC8 Low-Noise Adaptor (L.N.A.)
- NA-YC1 4-pin PWM splitter cable
- NA-EC1 30cm extension cable
- 4x NA-AV2 anti-vibration mounts
- NA-AVG2-LR anti-vibration gasket
- 4x NA-AVP1-LR load-relief anti-vibration pads
- Fan screws
