| Audio | ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080 |
| Chipset | AMD X870E |
| Form Factor | ATX Form Factor 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm ) |
| I/O Connectors | 2 x USB4 (40Gbps) ports (2 x USB Type-Cwith DP Alt mode), 6 x USB 10Gbps ports (5 x Type-A + 1 x USB Type-Cwith up to 30W PD**), 4 x USB 5Gbps ports (4 x Type-A), 1 x HDMI port, 1 x Wi-Fi module, 1 x Realtek 5Gb Ethernet port, 2 x Audio jacks, 1 x Optical S/PDIF out port, 1 x BIOS FlashBack button, 1 x Clear CMOS button |
| Integrated CPU Graphics | 1 x HDMI port, 2 x USB4 (40Gbps) ports support USB Type-C display outputs |
| LAN | 1 x Realtek 5Gb Ethernet, ASUS LANGuard |
| PCI Slots | AMD Ryzen 9000 & 7000 Series Desktop Processors: 1 x PCIe 5.0 x16 slot (supports x16 mode); AMD Ryzen 8700 & 8600 & 8400 Series Desktop Processors: 1 x PCIe 4.0 x16 slots (supports x8 mode); AMD Ryzen 8500 & 8300 Series Desktop Processors*: 1 x PCIe 4.0 x16 slots (supports x4 mode); AMD X870E Chipset: 1 x PCIe 4.0 x16 slot (supports x4 mode) |
| Processor Support | AMD Socket AM5 for AMD Ryzen 9000 & 8000 & 7000 Series Desktop Processors |
| RAID | AMD RAIDXpert2 Technology Ryzen 9000 & 8000 & 7000 Series Processors: RAID 0/1/5/10 |
| RAM Type/Bus/Max | 4 x DIMM slots, max. 256GB, DDR5; Supports up to: 8600+MT/s(OC)**/8200+MT/s(OC)*** with Ryzen 9000 Series Processors, 9600+MT/s(OC)**/9000+MT/s(OC)*** with Ryzen 8000 Series Processors, 8000+MT/s(OC)**/8000+MT/s(OC)*** with Ryzen 7000 Series Processors; ECC and Non-ECC, Un-buffered DIMM; Dual channel memory architecture ; Supports AMD Extended Profiles for Overclocking (EXPO); Supports DIMM Fit and DIMM Fit Pro; NitroPath DRAM Technology; ASUS Enhanced Memory Profile (AEMP) |
| Socket | AMD Socket AM5 |
| Storage Interface | Total supports 4 x M.2 slots and 4 x SATA 6Gb/s ports; AMD Ryzen 9000 & 7000 Series Desktop Processors: M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode), M.2_2 slot (Key M), type 2280/22110 (supports PCIe 5.0 x4 mode); AMD Ryzen 8700 & 8600 & 8400 Series Desktop Processors: M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode), M.2_2 slot (Key M), type 2280/22110 (supports PCIe 4.0 x4 mode); AMD Ryzen 8500 & 8300 Series Desktop Processors: M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode), M.2_2 slot (Key M), type 2280/22110 (Not supports); AMD X870E Chipset: M.2_3 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode), M.2_4 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode); 4 x SATA 6Gb/s ports |
| Warranty | |
| Weight | |
| Wireless & Bluetooth | Wi-Fi 7 (MediaTek MT7925), 2x2 Wi-Fi 7* (802.11be), Supports 2.4/5/6GHz frequency band, Supports Wi-Fi 7 160MHz bandwidth, Bluetooth v5.4 (support LE Audio) |
