• Data Transmission Controlled by the RTS Signal
  • DCE/DTE Selcetable
  • Point to Point, Multidrop, and Simplex/Duplex Link Selectable
  • Four Wire Full Duplex / Two Wire Half Duplex,monitor configuration Support
  • Compact Size
Function
Specification
Connectors
RS-232 DB-25 Female
RS-485 / RS-422 Four Terminal Block
RJ-11
Switches
SW1
DCE, DTE, Monitor
SW2
TxON, RxON
T-RTS, R-RTS
T-RTS, RxON
Data Rate
Up to 100 Kbps Under 1200m [4000']
Cable Length
1200 m [4000'] (Max.)
Power Consumption
DC 9V 1.35W (Max.)
Housing
Plastic
Weight
60 g
Dimensions (L x W x H)
54 x 74.5 x 18.5 mm
