Output

Output Power Capacity
280Watts /450 VA
Max Configurable Power
280Watts /450 VA
Nominal Output Voltage
230V
Output Voltage Distortion
Less than 5% at full load
Output Frequency (sync to mains)
47 - 53 Hz for 50 Hz nominal,57 - 63 Hz for 60 Hz nominal
Crest Factor
up to 5 : 1
Waveform Type
Stepped approximation to a sinewave
Output Connections
(4) IEC 320 C13
(2) IEC Jumpers

Input

Nominal Input Voltage
230V
Input Frequency
50/60 Hz +/- 3 Hz (auto sensing)
Input Connections
IEC-320 C14
Input voltage range for main operations
160 - 286V
Input voltage adjustable range for mains operation
151 - 302V

Batteries & Runtime

Battery Type
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Typical recharge time
5hour(s)
Replacement battery cartridge
RBC18
RBC Quantity
1
Typical Backup Time
at Half Load
19.4minutes (140 Watts)
Typical Backup Time
at Full Load
5.9minutes (280 Watts)
Runtime Chart
Smart-UPS SC

Communications & Management

Interface Port(s)
DB-9 RS-232
Control panel
LED status display with On Line : On Battery : Replace Battery and Overload indicators
Audible Alarm
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Emergency Power Off (EPO)
Optional

Surge Protection and Filtering

Surge energy rating
320Joules
Filtering
Full time multi-pole noise filtering : 0.7% IEEE surge let-through : zero clamping response time : meets UL 1449
Dataline protection
RJ-11 2-Way Modem/Fax/DSL splitter with protection (four wire dual lines),RJ45 10/100 Base-T Ethernet protection

Physical

Maximum Height
44.00mm
Maximum Width
432.00mm
Maximum depth
383.00mm
Rack Height
1U
Net Weight
10.18KG
Shipping Weight
11.73KG
Shipping Height
164.00mm
Shipping Width
476.00mm
Shipping Depth
589.00mm
Color
Grey
Units per Pallet
24.00

Environmental

Operating Environment
0 - 40C
Operating Relative Humidity
0 - 95%
Operating Elevation
0-3000meters
Storage Temperature
-15 - 45C
Storage Relative Humidity
0 - 95%
Storage Elevation
0-15000meters
Audible noise at 1 meter from surface of unit
38dBA
Online Thermal Dissipation
38.00BTU/hr

Conformance

Regulatory Approvals
C-tick,CE,GOST,VDE
Standard Warranty
2 years repair or replace
*With Tax/VAT
**The time to recharge to 90% of full battery capacity following a discharge to shutdown using a load rated for 1/2 the full load rating of the UPS.
