IMG 1 of 1
1 image(s) are available
for this product
Note: physical product may
vary from images displayed.
Our Price:
$462.90
RRP:
$467.50
You Save:
$4.60

Part Number:
126209
Usually Ships:
Order In More info
(?) Brand:
Manuf No:
VS-0108H
VS0108H
Shipping Weight:
2 KG (Includes product packaging)
8-Port HDMI Splitter
The VS0108H HDMI Splitter is the perfect solution for anyone who needs to send one source of digital high definition video to eight HDMI displays at the same time. It supports all HDMI-enabled equipment, such as DVD players, satellite set-top boxes and all HDMI displays. The VS0108H HDMI Splitter is HDCP (High Bandwidth Digital Content Protection) compliant, making it effective for use with all HDMI displays in home theater applications, as well as in corporate, educational and commercial settings.


Features
Connects one HDMI video source to 8 HDMI displays at the same time
Cascadable to three levels
Supports Dolby True HD and DTS HD Master Audio
Up to 60 Hz refresh rate
Long distance transmission - 20 m (24 AWG) and 15 m (28AWG)
Superior video quality - HDTV resolution of 480p, 720p, 1080i and 1080p (1920x1080); VGA, SVGA, SXGA, UXGA and WUXGA (1920x1200)
Supports 12-bit Deep Color for HDMI formats
DDC Compatible
HDMI 1.3b compliant
HDCP 1.1 compliant
HDMI CEC compliant
Signaling rates up to 2.25 Gbits in support of 1080p display
Rack Mountable
Package Content
1x VS0108H 8-Port HDMI Splitter
1x Power Adapter
1x Rack Mount Kit
1x User Guide
Diagram
+ View enlargement
Specification
Display Connections Direct 8
Max. 512 (via cascade)
Connectors Device HDMI In 1 x HDMI Type A Female (Black)
Display HDMI Out 8 x HDMI Type A Female (Black)
Power Jack 1 x DC Jack
LEDs Power 1 (Orange)
Input 1 (Green)
Output 1-8 8 (Green)
Video HDTV up to 1080p; computer up to WUXGA (1920x1200)
Power Consumption DC5.3V, 6.8W
Environment Operating Temp. 0-50C
Storage Temp. -20-60C
Humidity 0-80% RH, Non-condensing
Physical
Properties
Housing Metal
Weight 1.74 kg
Dimensions
( L x W x H )
43.20 x 15.40 x 4.40 cm
8-Port HDMI Splitter
The VS0108H HDMI Splitter is the perfect solution for anyone who needs to send one source of digital high definition video to eight HDMI displays at the same time. It supports all HDMI-enabled equipment, such as DVD players, satellite set-top boxes and all HDMI displays. The VS0108H HDMI Splitter is HDCP (High Bandwidth Digital Content Protection) compliant, making it effective for use with all HDMI displays in home theater applications, as well as in corporate, educational and commercial settings.


Features
Connects one HDMI video source to 8 HDMI displays at the same time
Cascadable to three levels
Supports Dolby True HD and DTS HD Master Audio
Up to 60 Hz refresh rate
Long distance transmission - 20 m (24 AWG) and 15 m (28AWG)
Superior video quality - HDTV resolution of 480p, 720p, 1080i and 1080p (1920x1080); VGA, SVGA, SXGA, UXGA and WUXGA (1920x1200)
Supports 12-bit Deep Color for HDMI formats
DDC Compatible
HDMI 1.3b compliant
HDCP 1.1 compliant
HDMI CEC compliant
Signaling rates up to 2.25 Gbits in support of 1080p display
Rack Mountable
Package Content
1x VS0108H 8-Port HDMI Splitter
1x Power Adapter
1x Rack Mount Kit
1x User Guide
Diagram
+ View enlargement
Specification
Display Connections Direct 8
Max. 512 (via cascade)
Connectors Device HDMI In 1 x HDMI Type A Female (Black)
Display HDMI Out 8 x HDMI Type A Female (Black)
Power Jack 1 x DC Jack
LEDs Power 1 (Orange)
Input 1 (Green)
Output 1-8 8 (Green)
Video HDTV up to 1080p; computer up to WUXGA (1920x1200)
Power Consumption DC5.3V, 6.8W
Environment Operating Temp. 0-50C
Storage Temp. -20-60C
Humidity 0-80% RH, Non-condensing
Physical
Properties
Housing Metal
Weight 1.74 kg
Dimensions
( L x W x H )
43.20 x 15.40 x 4.40 cm

No additional files, specification sheets, guides or documentation found for product.

No related products found.

Warranty: 1 Year Return to Base

Full manufacturers warranty details are available at the manufacturers web site.

Unless otherwise specified Techbuy is normally your first point of contact for warranty related returns, further information regarding our warranty policies and consumer guarantees is available on our policies and service & support pages.

To apply for return of a product just go to our returns page.

These terms are in addition to and do not affect any terms, conditions, guarantees and warranties implied by law.
