ATEN VS-108 Video Splitter - 1xHDB-15 Video-Input to 8xHDB-15 Video-Output, Max Resolution 1600x1200

No Longer Available

Part Number:

157365

(?) Brand:

ATEN

Manuf No:

VS108

Shipping Weight:

1 KG (Includes product packaging)
Estimate Shipping

Add to wishlist

Write a Review

Details Files Images & Video

All stock codes associated to this product

VS108, VS-108

8-Port Video Splitter

VS108 video splitters provides video input signal to 4 video outputs each at 200 MHz after duplication. Users can boost video signals from the video gain knob within a transfer range up to 65m

Features

	One video input to 8 video outputs.
	Cascadable to 3 levels-provides up to 512 video signals.
	Supports up to 200 MHz bandwidth.
	Long distance transmission - up to 65m.
	High video resolution - up to 1600 x 1200.
	DDC, DDC2, DDC2B Compatible (Port 1 only).
	Supports VGA, XGA, SVGA, UXGA and multisync monitors.
	OS Support: Windows 2000, Windows XP, Linux, Mac and Sun

Package Content

	1x 8-Port Video Splitter
	1x Power Adapter
	1x User Manual

Diagram

+ View enlargement

Specification

Display Connections		8
Connectors	Video In	1 x HDB-15 Male (Blue)
	Video Out	8 x HDB-15 Female (Blue)
	Power	1 x DC Jack (Black)
Switches	Video Gain	1 x Knob
LEDs	Power	1
Video Bandwidth		200 MHz
Video		1600 x 1200 @ 60Hz
Signal Range		Up to 65m (210')
Power Consumption		DC9V, 3.15W (Max.)
Environment	Operating Temp.	0-50C
	Storage Temp.	-20-60C
	Humidity	0-80% RH, Non-condensing
Physical Properties	Housing	Metal
	Weight	1.30 kg
	Dimensions (L x W x H)	22.40 x 15.20 x 5.20 cm

No additional files, specification sheets, guides or documentation found for product.

Warranty: 1 Year Return to Base

Full manufacturers warranty details are available at the manufacturers web site.
