Specifications
Scanner |
|
|
Scanner
Type |
Flatbed
color image scanner |
|
Photoelectric
Device |
Alternative
6 lines color Epson MatrixCCD® |
|
Optical
Resolution |
Epson
Dual Lens System |
|
|
4800
dpi and 6400 dpi |
|
Hardware
Resolution |
4800
x 9600 dpi |
|
|
6400
x 9600 dpi with Micro Step Driveâ„¢ technology |
|
Maximum
Resolution |
12,800
x 12,800 dpi |
|
Color
Bit Depth |
48-bits
per pixel internal / external1 |
|
Grayscale
Bit Depth |
16-bits
per pixel internal / external1 |
|
Output
Resolution |
4.0
Dmax |
|
Effective
Pixels |
40,800
x 56,160 (4800 dpi) |
|
|
37,760
x 62,336 (6400 dpi) |
|
Maximum
Scan Area |
8.5"
x 11.7" |
|
Light
Source |
ReadyScan
LED technology |
|
Scanning
Speed |
High-speed
mode: 4800 dpi |
|
|
Full
color: 10.8 msec / line (approx.) |
|
|
Monochrome:
10.8 msec / line(approx.) |
|
Optical
Density |
4.0
Dmax |
|
Optical
Density |
4.0
Dmax |
|
High
Pass Optics |
Anti-reflective
optical coatings |
|
|
High-reflection
mirror |
|
|
|
|
Transparency
Adapter |
|
|
Supported
Film Size |
35
mm slides (12 frames) |
|
|
35
mm film strips (18 frames) |
|
|
Medium
format film (1 frame, up to 6 x 20 cm) |
|
|
4"
x 5" film (1 frame) |
|
Dust/Scratch
Removal |
Digital
Dust Correction via Epson Scan |
|
|
Digital
ICE Technologies for Film and Prints |
|
|
Optional
Fluid Mount (scanning fluid and supplies not
included) |
|
Transparency
Size |
Transparency
adapter: 8" x 10" (max size) |
|
|
Transparency
adapter using film holders/fluid mount: 5.9" x 9.74" |
|
|
|
|
General |
|
|
Operating
Systems |
Windows®
8 – 8.1 |
|
|
Windows
7 |
|
|
Windows
Vista® |
|
|
Windows
XP® |
|
|
Windows
XP Professionnal x64 Edition |
|
|
Mac
OS® X 10.6.x – 10.10.x |
|
Temperature |
41°
to 95° F (5° to 35° C) |
|
|
|
|
Humidity |
|
|
Operating |
10
– 80% (no condensation) |
|
Storage |
10
– 85% (no condensation) |
|
|
|
|
Dimensions |
19.8"
x 12.1" x 6" (W x D x H) |
|
Weight |
14.6
lb |
|
|
|
|
Scan
Features |
|
|
Other |
Optional
Fluid Mount (scanning fluid and supplies not
included) |
|
Buttons |
1
button, Epson Scan |
|
|
|
|
Connectivity |
|
|
Standard
Connectivity |
Hi-Speed
USB 2.0 |
|
|
|
|
Scanner
Details |
|
|
Included
Software |
Epson
Scan with Epson Easy Photo Fix® technology |
|
|
LaserSoft
Imaging® SilverFast SE PLUS |
|
|
X-rite
i1Scanner with reflective/transparent IT8 targets |
|
Interfaces |
Hi-Speed
USB 2.0 |
|
Reliability |
MCBF:
100,000 cycles |
|
|
|
|
Power |
|
|
Rated
Voltage |
Input:
AC 100 – 120 V |
|
|
Output:
DC 24V, 1A |
|
Rated
Frequency |
50
– 60 Hz |
|
Power
Consumption |
Operation:
23 W |
|
|
Standby
Mode: 12 W |
|
|
Sleep
Mode: < 1.5 W |
|
|
Power
Off: 0.3 W |
