CPU |
AMD Ryzen 5000 Series/
5000 G-Series/
4000 G-Series/ 3000 Series Desktop Processors |
|
*Refer
to www.asus.com for CPU support list. |
|
Chipset |
B550 |
|
Memory |
4
x DIMM, Max. 128GB, DDR4 |
|
4866(OC)/4800(OC)/4600(OC)/4466(OC)/4400(OC)/4333(OC)/4266(OC)/4200(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133,
Un-buffered Memory* |
|
Dual
Channel Memory Architecture |
|
*
ECC memory (ECC mode) support varies by
CPU. |
|
*
Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists), and
memory frequency support depends on the CPU
types. |
|
Graphics |
1
x D-Sub |
|
1
x D-Sub port |
|
1
x DVI-D port |
|
1
x HDMI port** |
|
*
Graphics specifications may vary between CPU
types. |
|
**
Supports 4K@60Hz as specified in HDMI 2.1. |
|
Expansion
Slots |
AMD
Ryzen 5000 Series/ 3000 Series Desktop
Processors |
|
1
x PCIe 4.0 x16 slot (supports x16 mode) |
|
AMD
Ryzen 5000 G-Series/ 4000 G-Series Desktop
Processors |
|
1
x PCIe 3.0 x16 slot (supports x16 mode) |
|
AMD
B550 Chipset |
|
2
x PCIe 3.0 x1 slots |
|
Storage |
|
Supports
2 x M.2 slots and 4 x SATA 6Gb/s ports |
|
AMD
Ryzen 5000 Series/ 3000 Series Desktop
Processors |
|
M.2_1
slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 & SATA
modes) |
|
AMD
Ryzen 4000 G-Series Desktop Processors |
|
M.2_1
slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA
modes) |
|
AMD
B550 Chipset |
|
M.2_2
slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA
modes) |
|
4
x SATA 6Gb/s ports |
|
Support
RAID 0, 1, 10 |
|
Ethernet |
1
x Realtek 1Gb Ethernet |
|
ASUS
LANGuard |
|
Wireless
& Bluetooth |
2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) + BT5.2 |
|
Wi-Fi
6 |
|
2x2
Wi-Fi 6 (802.11 a/b/g/n/ac/ax) |
|
Supports
2.4/5GHz frequency band |
|
Bluetooth
v5.2 |
|
USB |
2
x USB 3.2 Gen 2 ports (2 x Type-A) |
|
4
x USB 3.2 Gen 1 ports (4 x Type-A) |
|
Front
USB:Total 6 ports |
|
1
x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1
ports |
|
2
x USB 2.0 headers support additional 4 USB 2.0
ports |
|
Audio |
Realtek
7.1 Surround Sound High Definition Audio
CODEC* |
|
-
Supports: Jack-detection, Multi-streaming, Front Panel
Jack-retasking |
|
-
Supports up to 24-Bit/192 kHz playback |
|
Audio
Features |
|
-
Audio Shielding |
|
-
LED-illuminated audio trace path design |
|
-
Premium audio capacitors |
|
-
Dedicated audio PCB layers |
|
*
A chassis with an HD audio module in the front panel is required to
support 7.1 Surround Sound audio output. |
|
Back
Panel I/O Ports |
2
x USB 3.2 Gen 2 ports (2 x Type-A) |
|
4
x USB 3.2 Gen 1 ports (4 x Type-A) |
|
1
x D-Sub port |
|
1
x DVI-D port |
|
1
x HDMI port |
|
1
x Wi-Fi Module |
|
1
x Realtek 1Gb Ethernet port |
|
3
x Audio jacks |
|
1
x PS/2 Keyboard/Mouse combo port |
|
Internal
I/O Connectors |
Fan
and Cooling related |
|
1
x 4-pin CPU Fan header |
|
1
x 4-pin CPU OPT Fan header |
|
2
x 4-pin Chassis Fan headers |
|
Power
related |
|
1
x 24-pin Main Power connector |
|
1
x 8-pin +12V Power connector |
|
Storage
related |
|
2
x M.2 slots (Key M) |
|
4
x SATA 6Gb/s ports |
|
USB |
|
1
x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1
ports |
|
2
x USB 2.0 headers support additional 4 USB 2.0
ports |
|
Miscellaneous |
|
1
x Addressable Gen 2 header |
|
2
x AURA RGB headers |
|
1
x Clear CMOS header |
|
1
x COM Port header |
|
1
x Front Panel Audio header (AAFP) |
|
1
x S/PDIF Out header |
|
1
x Speaker header |
|
1
x SPI TPM header (14-1pin) |
|
1
x 10-1 pin System Panel header |
|
Special
Features |
ASUS
5X PROTECTION III |
|
-
DIGI+ VRM |
|
-
LANGuard |
|
-
Overvoltage Protection |
|
-
SafeSlot Core |
|
-
Stainless-Steel Back I/O |
|
ASUS
Q-Design |
|
-
Q-DIMM |
|
-
Q-Slot |
|
ASUS
Thermal Solution |
|
-
VRM heatsink design |
|
AURA
Sync |
|
-
AURA RGB headers |
|
-
Addressable Gen 2 header |
|
Software
Features |
ASUS
Exclusive Software |
|
Armoury
Crate |
|
-
AURA Creator |
|
-
AURA Sync |
|
AI
Suite 3 |
|
-
Performance and Power Saving Utility |
|
TurboV
EVO |
|
EPU |
|
DIGI+
VRM |
|
Fan
Xpert 2+ |
|
-
EZ update |
|
-
Lighting Control |
|
ASUS
CPU-Z |
|
AI
Charger |
|
DAEMON
Tools |
|
MyASUS |
|
Norton
Anti-virus software (Free Trial version) |
|
WinRAR |
|
UEFI
BIOS |
|
ASUS
EZ DIY |
|
-
ASUS CrashFree BIOS 3 |
|
-
ASUS EZ Flash 3 |
|
-
ASUS UEFI BIOS EZ Mode |
|
BIOS |
256
Mb Flash ROM, UEFI AMI BIOS |
|
Manageability |
WOL
by PME, PXE |
|
Accessories |
Cables |
|
2
x SATA 6Gb/s cables |
|
Miscellaneous |
|
1
x ASUS Wi-Fi moving antennas |
|
1
x I/O Shield |
|
1
x M.2 SSD screw package |
|
Installation
Media |
|
1
x Support DVD |
|
Documentation |
|
1
x User manual |
