Billion's BiPAC 7401V(G)P series is a compact package of VoIP router series with powerful functionalities ideally designed for home and SOHO users to enjoy economical VoIP calls while having the mobility and high-speed and safe Internet access. This router series integrated with a single FXS port allows you to make VoIP calls simply by connecting the device to your regular telephone set. The additional FXO port enables you to make calls through PSTN Fixed-line while sharing a high-speed Internet access even faster. Rich Firewall security features such as SPI, DoS attack prevention, and URL Content Filtering are integrated to provide users unparalleled protection from hackers attack. The Quality of Service feature ensures a smooth net connection for inbound and outbound data with minimum traffic congestion.
Compliant with ADSL Standard
- G.dmt (ITU G.992.1)
Features & Specifications
ADSL Compliance
Compliant with ADSL Standard
- Full-rate ANSI T1.413 Issue 2
- G.hs (ITU G.994.1)
- ADSL over ISDN/U-R2
Compliant with ADSL2 Standard
- G.dmt.bis (ITU G.992.3)
- ADSL2 Annex M (ITU G.992.3 Annex M)
(Available for BiPAC 7401V(G)PM model only)
Compliant with ADSL2+ Standard
- G.dmt.bisplus (ITU G.992.5)
- ADSL2+ Annex M (ITU G.992.5 Annex M)
(Available for BiPAC 7401V(G)PM model only)
Network Protocols and Features
NAT, static routing and RIP-1/2
Universal Plug and Play (UPnP) Compliant
Dynamic Domain Name System (DDNS)
Virtual Server and DMZ
SNTP, DNS relay and IGMP proxy
POP3 (email account checking)
IGMP Snooping for video service
Firewall
Built-in NAT firewall
Stateful Packet Inspection (SPI)
Prevent DoS attacks including IP Spoofing, Land Attack, Smurf Attack, Ping of Death, TCP SYN Flooding, etc.
Packet Filtering - port, source IP address, destination IP address, MAC address
URL Content Filtering - string or domain name detection in URL string
VoIP
One RJ-11 FXS ports for connecting to regular telephones
One RJ-11 FXO port for PSTN Fixed-line
Compliant with SIP standard (RFC3261)
Supports G.711 A/m law, and G.729 Audio Codec standards
Supports Telephony Features: call waiting, silence suppression, voice activity detection (VAD), comfort noise generation (CNG), G.168 line echo cancellation, caller ID (Bell 202,V23)
Voice over data, QoS control to ensure higher voice quality
Automatic fallback to PSTN Fixed-line when the Internet or VoIP service is not available.
Wireless 802.11g (BiPAC 7404VGP)
Compliant with IEEE 802.11g and 802.11b standards
2.4 GHz - 2.484G Hz frequency range
Up to 54 Mbps wireless operation rate
64/128 bits WEP supported for encryption
Wireless security with WPA-PSK/WPA2-PSK support
WDS repeater function support
IPTV Application*
IGMP Snooping
Virtual LAN (VLAN)
Quality of Service (QoS)
Quality of Service Control
Supports the DiffServ approach
Traffic prioritization and bandwidth management based-on IP protocol, port number and address
ATM and PPP Protocols
ATM Adaptation Layer Type 5 (AAL5)
Multiple Protocol over AAL5 (RFC 2684, formerly RFC 1483)
Bridged or routed Ethernet encapsulation
VC and LLC based multiplexing
PPP over Ethernet (PPPoE)
PPP over ATM (RFC 2364)
Classical IP over ATM (RFC 1577)
MAC Encapsulated Routing (RFC 1483 MER)
OAM F4/F5
Models & Standards Support
BiPAC 7401V(G)PA: Annex A
BiPAC 7401V(G)PM: Annex A & Annex M
BiPAC 7401V(G)PB: Annex B & U-R2
Annex A and Annex M: ADSL over POTS
Annex B and Annex U-R2: ADSL over ISDN
Management
Quick Installation Wizard and Auto-scan ADSL settings
Web-based GUI for remote and local management
Firmware upgrade and configuration data upload and download via
Web-based GUI
Embedded Telnet server for remote and local management
Available Syslog monitoring
SNMP v3, MIB-I and MIB-II support
Supports DHCP server/client/relay
Hardware Specification
Physical Interface
WLAN: detachable antenna (BiPAC 7401VGP)
WAN: ADSL port
Telephone: 1-port FXS
1-port FXO (For PSTN Fixed-line support)
LAN: 4-port 10/100M auto-crossover (MDI/MDI-X) Switch
Console: the Ethernet Port # 4 can be also connected to console
Factory default reset button
Power jack
Power switch
Physical Specification
Dimensions: 7.09" x 4.72" x 1.57" (180mm x 120mm x 40mm)
Power Requirement
Input: 12V DC, 1.2A
Operating Environment
Operating temperature: 0 ~ 40 C
Storage temperature: -20 ~ 70 C
Operating Humidity: 20% ~ 95% non-condensing
Networking
