GIGABIT PERFORMANCE
The unmanaged switch offers Gigabit speeds to minimize transfer times and greatly enhance the ability to stream high-bandwidth files to connected devices without interference.
POWER WHERE YOU NEED IT
PoE support lets you deploy network systems such as wireless access, IP telephony, or video surveillance solutions more quickly and at a lower cost, without having to install separate power supplies for individual devices.
PLUG AND PLAY CONVENIENCE
Linksys unmanaged switches offer a quick and easy solution to extend your office network with plug-and-play installation.
QUALITY OF SERVICE (QOS) TRAFFIC PRIORITIZATION
QoS traffic prioritization gives precedence to particular devices or activities to ensure mission-critical data throughput is maintained regardless of network congestion. Auto-sensing ports automatically optimize speed for each connected device.
Specifications
| Model: |
LGS108P |
| Standards: |
IEEE 802.3, 802.3u, 802.3x, 802.3ab, 802.3az, 802.3af, and 802.3at (PoE+) |
| Number of Ports: |
8-port switch with 4 PoE+ ports (first 14 ports) and dedicated PoE power budget of 50 W |
| Bandwidth: |
16 Gbps (non-blocking) |
| Performance: |
Full line rate and forwarding rate of 64B frame at: 1.488 Mpps for 1000M port, 0.1488 Mpps for 100M port, 0.01488 Mpps for 10M port |
| Quality of Service: |
802.1p and DSCP |
| Status LEDs: |
Link, speed, activity, and PoE indicators |
| Power Supply: |
External |
| Power: |
54 VDC, 1.2 A |
| Power Saving: |
Cable connected detection Sleep mode |
| Power Consumption n Idle/Use (100% Traffic) |
3.83 W / 7.0 W |
| Fan |
None |
| Unit Dimensions |
210 x 104 x 25 mm (81.9 x 40.56 x 9.75 in.) |
| Unit Weight |
0.556 kg (1.23 lbs) |
| Temperature (Operating) |
050C (32122F) |
| Temperature (Storing) |
-4070C (-40158F) |
| Humidity (Operating) |
1090% (non-condensing) |
| Humidity (Storing) |
1090% (non-condensing) |
| Certifications |
FCC Class A, CE |
| Mounting |
Wall mount |
| Minimum System Requirements |
Connected devices need Ethernet connectivity and Ethernet cables |
| Warranty and Support |
Lifetime limited warranty |
| Package Contents |
Linksys LGS108P 8-Port Gigabit Ethernet PoE Switch, Power Adapter, Quick Start Guide |
| MAC Address Table |
8K |
