HARDWARE
FEATURES |
|
Processor |
Qualcomm Atheros
Enterprise 560MHz CPU, MIPS 74Kc |
|
Memory |
64MB DDR2 RAM, 8MB
Flash |
|
Interface |
1 10/100Mbps Shielded
Ethernet Port (LAN0,Passive PoE in) |
|
1 10/100Mbps Shielded
Ethernet Port (LAN1, Passive PoE Passthrough) |
|
1 Grounding
Terminal |
|
1 Reset
Button |
|
Power
Supply |
Passive Power over
Ethernet via LAN0 (+4,5pins; -7,8pins) |
|
Voltage range:
16-27VDC |
|
Dimensions (W X D X
H) |
113.12.4 inch
(2767960mm) |
|
Power
Consumption |
14 Watts
Max |
|
Note: When deployed
using Passive PoE, the power drawn from the power
source |
|
will be higher by some
amount depending on the length of the connecting
cable. |
|
Antenna
Type |
Built-in 16dBi 2x2
Dual-polarized Directional Antenna |
|
Beam Width: 45
(H-Plane) / 30 (E-Plane) |
|
Note: For more details,
please refer to datasheet |
|
Protection |
15KV ESD
Protection |
|
6KV Lightning
Protection |
|
Enclosure |
Outdoor ASA stabilized
plastic material |
|
IPX5 waterproof
Certification |
|
|
|
|
WIRELESS
FEATURES |
|
Wireless
Standards |
IEEE 802.11a/n (with
Pharos MAXtream disabled) |
|
Proprietary
Protocol |
TDMA Mode (with Pharos
MAXtream enabled) |
|
Wireless
Speeds |
Up to 300Mbps
(40MHz,Dynamic) |
|
Up to 144.4Mbps
(20MHz,Dynamic) |
|
Up to 72.2Mbps
(10MHz,Dynamic) |
|
Up to 36.1Mbps
(5MHz,Dynamic) |
|
Frequency |
5.15~5.85GHz |
|
Note: Available
operating frequency may vary depending on the |
|
limitations of the
countries or regions in which the device is used. |
|
Transmission
Power |
27dBm/500mw (Adjustable
power by 1dBm) |
|
Note: Maximum
transmission power may vary across different channels
depending |
|
on the limitations of
the countries or regions in which the device is used. |
|
|
|
|
SOFTWARE
FEATURES |
|
Wireless
Configurations |
Pharos MAXtream TDMA
Technology |
|
802.11a/n
Modes |
|
Selectable Channel
Width: 5/10/20/40MHz |
|
Automatic Channel
Selection |
|
Transmission Power
Control |
|
Dynamic Frequency
Selection (DFS) |
|
WDS
Enable/Disable |
|
Security: WPA/WPA2,
WPA-PSK/WPA2-PSK (AES/TKIP) Encryption, 64/128/152-bit WEP
Encryption |
|
SSID Broadcast
Enable/Disable |
|
Multi-SSID with VLAN
Tagging (AP mode only) |
|
Distance/ACK Timeout
Setting |
|
Wireless MAC Address
Filter |
|
Wireless
Advanced: |
|
> Beacon
Interval/RTS Threshold/Fragmentation |
|
>Threshold/DTIM
Interval/AP Isolation/Short GI/Wi-Fi Multimedia |
|
Management |
Discovery and Remote
Management via Pharos Control application |
|
HTTP/HTTPS Web-based
management |
|
System
Log |
|
SNMP
Agent(v2c) |
|
Ping Watch
Dog |
|
Dynamic
DDNS |
|
SSH
Server |
|
System
Tools |
Wireless Signal Quality
Indicators: |
|
Signal
Strength/Noise/Transmit CCQ/CPU/Memory |
|
Monitors:
Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP |
|
Spectrum
Analyzer |
|
Speed
Test |
|
Ping |
|
Traceroute |
|
System-level
Optimizations |
Optimized IGMP
Snooping/Proxy for multicast applications |
|
Hardware watch
dog |
|
|
|
|
POE ADAPTER
FEATURES |
|
Interfaces |
1 AC Jack with Earth
Ground |
|
1 10/100/1000Mbps
Shielded Ethernet Port (Power + Data) |
|
1 10/100/1000Mbps
Shielded Ethernet Port (Data) |
|
Efficiency |
>80% |
|
Button |
Remote Reset
Button |
|
Certifications |
CE/FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark |
|
Power Status
LEDs |
0~0.8A:
Green |
|
0.8A~1.0A:
Red |
|
Output |
24VDC, 1.0A
Max |
|
+4, 5pins; -7, 8pins.
(Support up to 60m Power over Ethernet) |
|
Input
Voltage |
100VA~240VAC @
50Hz~60Hz |
|
Dimensions(W x D x
H) |
1105733.5mm |
|
Input
Current |
0.8A Max @
100VAC |
|
Input |
100-240VAC,
50/60Hz |
|
Output
Voltage |
24VDC(+4,5pins;
-7,8pins) |
|
|
|
|
OTHERS |
|
Certification |
CE, FCC, RoHS,
IPX5 |
|
Package
Contents |
Outdoor Wireless
CPE |
|
24V 1A Passive PoE
Adapter |
|
Pole Mounting
Straps |
|
AC Power
Cord |
|
Installation
Guide |
|
System
Requirements |
Microsoft Windows 98SE,
NT, 2000, XP, Vista or Windows 10, Windows 8, |
|
Windows 7, MAC OS,
NetWare, UNIX or Linux. |
|
Note: We recommend you
to use one of following Web browsers for an improved
user |
|
experience: Google
Chrome, Safari, and Firefox. IE browsers are not
recommended. |
|
Environment |
Operating Temperature:
-30C~70C (-22~158) |
|
Storage Temperature:
-40~70
(-40~158) |
|
Operating Humidity:
10%~90% non-condensing |
|
Storage Humidity:
5%~95% non-condensing |
