Overview
- Brings Wi-Fi dead zone to life with strong Wi-Fi expansion at combined
speed of up to 1.2Gbps.
- Operates over both the 2.4GHz band(300Mbps) and 5GHz band(867Mbps) for
more stable wireless experience.
- Intelligent signal light helps to find the best location for
optimal Wi-Fi coverage by showing the signal strength.
- Works with any Wi-Fi router or wireless access point.
Stable Dual Band Wi-Fi Extension to Bring Dead Zones to
Life
High-Speed Dual Band Wi-Fi for Better Connections
The RE305 lets you keep more devices connected at the same time with its
2.4GHz 300Mbps and 5GHz 867Mbps dual bands. Use the 2.4GHz band to send email
and browse the web, and the 5GHz band for gaming and HD streaming.
Perfect Location at a Glimpse
An Intelligent Signal light helps you quickly find the best location to
install the RE305.
Built-in Access Point Mode
RE305 is more than a wireless range extender. Simply plug the Ethernet cable
into its Ethernet port to easily turn your wired internet connection into a dual
band wireless access point.
Easy Management and Remote Control
The RE305 works with all Wi-Fi routers. You can use TP-Link's free Tether app
to set up the range extender from any Android or iOS device in minutes. This
feature-rich phone app allows you to enjoy not only hassle-free installation,
but also access to advanced network management, all at your fingertips.
Specifications
|
HARDWARE FEATURES |
|
|
Plug Type |
EU, UK, US |
|
Standards and Protocols |
IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11a, IEEE
802.11b |
|
Interface |
1 x 10/100M Ethernet Port (RJ45) |
|
Button |
WPS Button, Reset Button |
|
Power Consumption |
7.3Wmax power consumption |
|
Antenna |
2 x external |
|
Dimensions ( W x D x H ) |
3.1 x 3.0 x 3.0 in. (80 x 78 x 77mm) |
|
|
|
WIRELESS FEATURES |
|
|
Frequency |
2.4GHz &5GHz(11ac) |
|
Signal Rate |
5GHz:Up to 867Mbps |
|
2.4GHz:Up to 300Mpbs |
|
Reception Sensitivity |
5GHz |
|
11a 6Mbps:-91dBm@10% PER |
|
11a 54Mbps: -74dBm@10% PER |
|
11ac HT20 mcs8: -68dBm@10% PER |
|
11ac HT40 mcs9: -63dBm@10% PER |
|
11ac HT80 mcs9: -59dBm@10% PER |
|
2.4GHz |
|
11g 54M: -79dBm@10% PER |
|
11n HT20 mcs7: -77dBm@10% PER |
|
11n HT40 mcs7: -74dBm@10% PER |
|
Wireless Modes |
Range Extender/Access Point |
|
Wireless Statistic |
|
Concurrent Mode boost both 2.4G/5G Wi-Fi band |
|
Wireless Functions |
Wireless Statistic |
|
Concurrent Mode boost both 2.4G/5G Wi-Fi band |
|
Access Control |
|
LED Control |
|
Domain Login Function |
|
Wireless Security |
64/128-bit WEP |
|
WPA-PSK / WPA2-PSK |
|
Transmission Power |
<17dBm(2.4GHz) |
|
<17dBm(5GHz) |
|
|
|
OTHERS |
|
|
Certification |
CE, FCC, RoHS |
|
Package Contents |
AC1200 Wi-Fi Range Extender RE305 |
|
Quick Installation Guide |
|
Box Dimensions (W X D X H) |
6.15 x 4 x 3.7 in. (156.5 x 101.5 x 95mm) |
|
System Requirements |
Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, 8, 10, Mac
OS, NetWare, UNIX or Linux. |
|
Environment |
Operating Temperature: 0C~40C (32F~104F) |
|
Storage Temperature: -40C~70C (-40F~158F) |
|
Operating Humidity: 10%~90% non-condensing |
|
Storage Humidity: 5%~90%
non-condensing |
