GENERAL |
Device Type | Switch - 8 ports - unmanaged |
Enclosure Type | Desktop |
Subtype | Gigabit Ethernet |
Ports | 8 x 10/100/1000 |
Performance | Switching capacity: 16 Gbps Throughput (64-byte packet size): 11.8 Mpps Latency (100 Mbps): 3 s Latency (1000Base-T): 2.6 s |
MAC Address Table Size | 4096 entries |
Features | Flow control, full duplex capability, auto-negotiation, auto-uplink (auto MDI/MDI-X), half duplex mode, Quality of Service (QoS), fanless, DiffServ Code Point (DSCP) support |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3az |
Flash Memory | 1.5 MB |
EXPANSION / CONNECTIVITY |
Interfaces | 8 x 1000Base-T RJ-45 |
POWER |
Power Device | Internal power supply |
Voltage Required | AC 120/230 V (50/60 Hz) |
Power Consumption Operational | 4.5 Watt |
MISCELLANEOUS |
Compliant Standards | Plug and Play, CISPR 24, EN55022, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN55024, UL 60950, CISPR 22, IEC 60950-1, EN 60950-1, FCC Part 15 B Class A, CAN/CSA C22.2 No. 60950-1-03 |
DIMENSIONS &WEIGHT |
Width | 15.77 cm |
Depth | 10.49 cm |
Height | 2.69 cm |
Weight | 500 g |
MANUFACTURER WARRANTY |
Service &Support | Limited warranty - lifetime |
ENVIRONMENTAL PARAMETERS |
Min Operating Temperature | 0 C |
Max Operating Temperature | 40 C |
Humidity Range Operating | 15 - 95% (non-condensing) |
Min Storage Temperature | -40 C |
Max Storage Temperature | 70 C |
Humidity Range Storage | 15 - 95% (non-condensing) |
