Edimax 9260TX-E Gigabit Ethernet network
Features
- Complies with PCI Express 1.1 x1 PCI Express standard
- IEEE 802.3, 802.3u, 802.3ab and 802.3x standards
- Supports 10/100/1000Mbps Auto Negotiation and Jumbo Frame
- Supports IEEE802.3x full-duplex Flow Control
- Supports IEEE802.1Q VLAN Tagging and IEEE802.1P Layer2 Priority Encoding
- Supports Wake on LAN and ACPI power management
- Supports IEEE802.3az energy efficient Ethernet function
- Includes a low-profile bracket
- Plug-and-Play
- Supports drivers for Novell 5.X/6.X, Windows 98/ME/2000/XP/Vista/7/8,
Linux 2.4.x
Overview
The EN-9260TX-E network adapter for PCs with PCI Express slots offers the
latest technology in power management and Gigabit Ethernet network connectivity
capability. The EN-9260TX-E’s full bandwidth capability boasts a robust 1000Mbps
capability through the PCI Express bus architecture. There’s no need to purchase
a new switch or broadband router since the adapter’s auto-negotiation feature
works with your existing switch, broadband router or hub to provide the highest
network speed available (10/100 or 1000 Mbps). The adapter’s automatic full
duplex capability further increases bandwidth and eliminates packet collisions
by allowing data to flow in both directions at the same time.
First-class Reliability
The EN-9260TX-E’s exceptional chipset offers increased bandwidth and more
functionality than other standard PCI network adapters. The adapter is
specifically designed to carry the full bandwidth capacity of the PCI Express
bus of 2.5 Gbps, thus eliminating collisions and latencies that exist with
current 32 and 64 bit PCI bus architectures.
Ease of Installation & Configuration
The EN-9260TX-E offers ease and flexibility of installation and configuration
of the adapter through Plug & Play technology. Simply place the adapter into
the PCI Express slot in your PC and then turn on the PC; plug-n-play
automatically detects the new device. The adapter is fully compatible with
Ethernet, Fast Ethernet, and Gigabit Ethernet networks and the adapter’s
10/100/1000 Mbps auto negotiation ports eliminate any need for manual switching.
Best of all, the adapter is supported by all major operating systems including
Vista and Linux OS.
User-friendly Setup CD Wizard and Driver
To facilitate network connectivity, the EN-9260TX-E includes a user-friendly
setup CD wizard. Its user interface simplifies driver installation for immediate
use of the device.
Specifications
HARDWARE
INTERFACE |
|
|
PCI
Express Interface |
|
One
10/100/1000 Mbps LAN port |
INSTALLATION
KIT |
Setup
Wizard program with Driver setup |
|
|
SYSTEM
REQUIREMENTS |
CPU:
Pentium III 1G above or similar |
|
Memory
size: 256MB RAM |
|
One
CD-ROM drive |
|
Hard
Disk: Min. of 100MB disk space |
|
One
available PCI express slot |
|
OS:
Novell 5.X/6.X, Windows 98/ME/2000/XP/Vista/7/8, Linux
2.4.x |
|
OS |
DIMENSION |
64x39
mm |
COMPLIED
STANDARDS |
IEEE
802.3, IEEE 802.3u, IEEE 802.3ab, |
|
IEEE802.3x,
802.1q, 802.1p, 802.3az |
BUS
ARCHITECTURE |
PCI
V 2.3/2.2/2.1, 32-bit, 66/33MHz |
LED
Indicators |
Link
/ACT |
|
1000M |
HUMIDITY |
Operating:
10~90%RH (non-condensing) |
|
Storage:
5 to 95% RH (non-condensing) |
TEMPERATURE |
Operating:
0~40℃ |
|
Storage:
-40~70℃ |
CERTIFICATIONS |
CE,
FCC |
