General |
–
Intel® X540 10GbE controller with integrated 10GBase-T copper
PHYs |
|
–
Compact size low-profile standard form factor |
|
–
PCI-E x8 2.1 (2.5GT/s or 5GT/s) interface |
|
–
Dual RJ-45 connectors with speed up to 10Gb/port |
|
–
Load balancing on multiple CPUs |
|
–
Intel® PROSet Utility for Windows® Device Manager |
|
–
Maximum power consumption: about 13W |
|
|
I/O
Features |
–
Intel® QuickData Technology: DMA engine that enhances data acceleration
and lowers CPU usage |
|
–
Support jumbo frames of up to 15.5KB |
|
–
802.1q VLAN sup |
|
–
Two integrated independent 10GBase-T interfaces operate at 10GBase-T
(10Gb/s) and 1000Base-T (1Gb/s) modes |
|
–
Direct Cache Access (DCA) to avoid cache misses |
|
–
MSI-X support to minimize interrupt overhead of and allow load-balancing
between multiple cores/CPUs |
|
Receive
and Transmit Side Scaling for Windows environment and Scalable I/O for
Linux environments |
|
|
Performance
Features: |
–
TCP/UDP Segmentation Offload |
|
–
IPv6 Support for IP/TCP and IP/UDP Receive Checksum
Offload |
|
–
Supports Fibre Channel over Ethernet (FCoE) |
|
–
Low latency interrupts |
|
–
DCA support |
|
|
Virtualization
Features |
–
Support for Virtual Machine Device Queues (VMDq and Next-generation
VMDq) |
|
–
L2 Ethernet MAC address and VLAN filters |
|
–
PC-SIG SR-IOV implementation |
|
–
Advanced Packet Filtering |
|
–
VLAN support to allow creation of multiple VLAN
segments |
|
–
VXLAN through Software |
|
|
Compliance/Environmental |
RoHS
Compliant 6/6, Pb Free |
|
|
Manageability
Features |
–
Preboot eXecuation Environment (PXE) support |
|
–
Simple Network Management Protocol (SNMP) and |
|
Remote
Network Monitoring (RMON) statistics counters |
|
–
iSCSI remote boot |
|
–
Asset Management Features |
OS
Support |
–
Windows® Server 2008 R2 SP1, 7 SP1, Server 2008 SP2, Vista
SP2, |
|
Server
2003 R2, 2003 SP2, 2008 SP2 |
|
–
Linix Kernel version 3.1.x & 2.6.X |
|
–
FreeBSD 8 |
Cables
Support |
–
RJ-45 Category-6 up to 55m; Category-6A up to 100m |
|
|
Operating
Conditions |
–
Operating temperature: 0°C to 55°C |
|
|
Physical
Dimensions |
–
Card PCB dimensions: 14.99cm x 6.93cm (5.9in x 2.73in)
(LxW) |
|
–
Height of end brackets: standard - 12cm (4.725in), low-profile – 7.94cm
(3.13in) |
|
|
Optional
Accessories |
–
CBL-NTWK-0603: RJ45 CAT6A 550MHz Rated Blue 3 ft patch
cable |
|
–
CBL-NTWK-0604: RJ45 CAT6A 550MHz Rated Blue 5 ft patch
cable |
|
–
CBL-NTWK-0605: RJ45 CAT6A 550MHz Rated Blue 6 ft patch
cable |
|
–
CBL-NTWK-0606: RJ45 CAT6A 550MHz Rated Blue 9 ft patch
cable |
|
–
CBL-NTWK-0609: RJ45 CAT6A 550MHz Rated Blue 15 ft patch
cable |
|
–
CBL-NTWK-0610: RJ45 CAT6A 550MHz Rated Blue 18 ft patch
cable |
|
–
CBL-NTWK-0611: RJ45 CAT6A 550MHz Rated Blue 21 ft patch
cable |
|
–
CBL-NTWK-0612: RJ45 CAT6A 550MHz Rated Blue 24 ft patch
cable |
