Dell 210-AEVX Networking N1524 Switch



Overview

Update your network access

Dell Networking N1500 Series Switches - Update your network access

The N1500 switch series offers a power-efficient Gigabit Ethernet (GbE) network-access switching solution with integrated 10GbE uplinks. The N1500 switch series has high-performance capabilities and wire-speed performance, utilizing a non-blocking architecture to handle unexpected traffic loads easily. These switches offer simple management and scalability via a 40Gbps (full-duplex) high-availability stacking architecture that allows management of up to four switches from a single IP address. Support for OpenFlow 1.3 provides interoperability with industry-standard OpenFlow controllers.

Deliver clean power to network devices with PoE+ support

Dell Networking N1500 Series Switches - Deliver clean power to network devices with PoE+ support

The Dell Networking N1500 Series has options for up to 48 Power-over-Ethernet Plus (PoE+) ports. You can attach devices with high power requirements (up to 30.8 watts) without running a separate power cable. PoE+ is particularly useful in older buildings where installing power to multiple, widespread locations can be prohibitively expensive.

Designed for efficiency

Built to help keep operating costs down, the N1500 Series can operate at temperatures up to 113F (45C) to help reduce cooling costs. Improve your overall efficiency with these great features:

Dell Networking N1500 Series Switches - Designed for efficiency

  • Z80 Plus-certified efficient integrated power supply
  • Redundant variable-speed cooling fans
  • Energy-efficient Ethernet and low-power physical layer (PHYs) to help reduce power to inactive ports and idle links

Simplify management with advanced features

The Dell Networking N1500 Series delivers easy deployment, outstanding interoperability and a level learning curve for network administrators. And with Dell Networking OS 6, you maintain consistent configurations across all N-Series products with comprehensive features:

  • One common command line interface (CLI) and graphical user interface (GUI) that use a well-known command language to help skilled network administrators become productive quickly
  • USB auto-configuration that helps network administrators rapidly deploy mirrored configurations to numerous devices by simply inserting a USB key
  • A variety of enterprise-class features with familiar and intuitive configuration and management commands, including the latest open-standard protocols and smart integration technologies to help make smoothly operating multi-vendor networks possible

Deploy with confidence at any scale

With high throughput and capacity to handle unexpected workloads, the N1500 Series switches are ideal solutions for fast-growing GbE networks that require high-density aggregation with seamless redundancy and availability. Take advantage of the following features:

  • Data rates up to 176Gbps (full duplex) and a forwarding rate of up to 164Mpps
  • Four 10GbE SFP+ ports for high-speed uplinks and a stacking architecture up to four units at 40Gbps
  • Switch stacks up to 200 1GbE ports that can be managed from a single screen or IP address

Dell EMC offers complete end-to-end services

Optimizing the IT lifecycle is vital. Dell EMC has expert services*for all lifecycle phases that save you time and resources, reduce effort, and improve your IT experience.

ProSupport Enterprise Suite

ProSupport Enterprise Suite

Gain the freedom to focus on your business transformation with the support expertise and insights Dell EMC is known for across the globe. Choose the right support based on the criticality of specific systems with available automated predictive analysis, collaborative third-party assistance and service account management.

ProDeploy

ProDeploy

ProDeploy Enterprise Suite helps you get more out of technology starting on day one. Trust Dell EMC experts to lead deployments from basic hardware installations through planning, configuration and complex integrations. Our complete suite of deployment services and professional certifications helps you achieve business outcomes today and tomorrow.

Training

Training Certification

Education Services offers an expansive suite of training services with a variety of delivery methods to choose from including instructor-led training, self-paced online training and virtual instructor-led training. With comprehensive and flexible training programs, we make it easy to ensure your staff has the skills they need to successfully manage and utilize your new technology to its full potential.

Consulting

Consulting

Consulting services give expert guidance to help you grow, optimize and transform your IT environment at your own pace and budget. We employ a broad range of certified consultants and engineers, backed by program management teams, who can deliver deep technical expertise. We give you the confidence that your project will be done right and on time.

Specifications

Switch Attributes

Line-rate Layer 2 switching

standard

Line-rate Layer 3 routing

standard

CPU Memory

1GB

Flash Memory

256MB

Packet Buffer Memory

1.5MB

Dual firmware images on-board

standard

Temperature sensors for environmental monitoring

standard

Cable diagnostics

Standard

Optical transceiver (SFP/SFP+) diagnostics

standard

Switch auditing support

standard

UDLD

standard

Switch Fabric Capacity (full duplex)

128Gbps

Forwarding Rate

128Mpps

Stacking Attributes

Integrated rear mini-SAS stacking ports

not available

User port stacking

Y

Maximum stacking distance (meters)

100

Maximum stacking speed (full-duplex)

40Gbps

Optional Features

Modules (optional)

2-port 10 Gigabit BASE-T RJ45 hot swappable uplink module

not available

2-port 10 Gigabit SFP+ hot swappable uplink module

not available

4-port 10 Gigabit BASE-T RJ45 hot swappable module

not available

4-port 10 Gigabit SFP+ hot swappable module

not available

2-port 40 Gigabit QSFP+ hot swappable module

not available

Power Supplies (optional)

200w, hot swappable, with V-Lock, adds redundancy to non-PoE switches

not available

715w, hot swappable, adds redundancy or to power all PoE+ ports fully

not available

1100w, hot swappable, adds redundancy or to power all PoE+ ports fully

not available

RPS720 External Power Supply for N1500 non-POE (720 watts)

option available

MPS1000 External Power Supply for N1500 POE+ Switches (1000 watts)

not available

Power and Cooling Hardware

Internal hot swappable power supply bays

not available

Hot swappable power supplies (included)

not available

Integrated power supply (not removable)

standard

External power supply

option available

Power supply redundancy

option available

Removable fans)

not available

Redundant fans

standard

Variable speed fans

standard

Air flow

IO to PSU (normal)

Port Attributes

Standard Traffic-Port Attributes

Integrated 10GbE SFP+ dedicated ports (beyond standard ports)

4

Integrated GbE SFP combo ports

not available

Integrated GbE 10/100/1000BASE-T RJ45 combo ports

not available

Integrated 40GbE QSFP+ dedicated ports

not available

Modular Traffic-Port Attributes

Hot swappable expansion module bay

not available

Module support for 10GbE

not available

Module support for 40GbE

not available

Support for 40GbE to 4x 10GbE breakout

not available

Traffic-Port Features

Auto-negotiation for speed and flow control

standard

Auto MDI/MDIX

standard

Port mirroring

standard

Flow-based port mirroring

standard

Broadcast storm control

standard

Energy Efficient Ethernet per port settings

standard

Port Profile support including Admin profiles

standard

Management- & Configuration-Port Attributes

1 RJ45 console/management port with RS232 signaling

standard

1 Out-of-Band (OOB) Management Port (10/100/1000BASE-T)

Not available

1 USB (Type A) port for configuration

standard

Standard Port Attributes

24x 1GbE RJ45 auto-sensing (1Gb/100Mb/10Mb) fixed ports

Power-over-Ethernet Plus (PoE+)

not available

Maximum PoE Watts per port

not available

Chassis

Rack Height

1U

Rack-mounting kit

Y

ReadyRails rack mounting system, no tools required

not available

Dimensions in inches (H x W x D)

1.7 x 17.3 x 10.1

Dimensions in millimeters (H X W X D):

43.5 x 440.0 x 257.0

Approximate Weight in pounds (without modules)

6.6

Approximate Weight in kilograms (without modules)

3

Environmental Operating Conditions

Operating Temperature in Celsius

0° to 45° C

Operating Temperature in Fahrenheit

32° to 113° F

Storage Temperature in Celsius

-40° to 65° C

Storage Temperature in Fahrenheit

-40° to 149° F

Operating Relative Humidity

95%

Storage Relative Humidity

85%

Power Supply Efficiency

80% or better in all operating modes

Power Supply (Watts)

40

Max Thermal Output (BTU/hr)

103.1

Power Consumption Max (Watts)

30.2
