Model
Name |
XT8
(B-2-PK) |
|
Network
Standard |
IEEE
802.11a |
|
IEEE
802.11b |
|
IEEE
802.11g |
|
IEEE
802.11n |
|
IEEE
802.11ac |
|
IEEE
802.11ax |
|
IPv4 |
|
IPv6 |
|
AX
technology |
Yes |
|
Data
Rate |
802.11n
: up to 300 Mbps |
|
802.11ac
(1024QAM) : up to 3466 Mbps |
|
802.11ax
(2.4GHz) : up to 574 Mbps |
|
802.11ax
(5GHz) : up to 4808 Mbps |
|
Antenna |
Internal
antenna x 6 |
|
Transmit/Receive |
2.4
GHz 2 x 2 |
|
5
GHz-1 2 x 2 |
|
5
GHz-2 4 x 4 |
|
Processor |
1.5
GHz quad-core processor |
|
Memory |
256
MB Flash |
|
512
MB RAM |
|
Boosts
speed |
OFDMA
(Orthogonal Frequency Division Multiple
Access) |
|
Beamforming:
standard-based and universal |
|
1024-QAM
high data rate |
|
20/40/80/160
MHz bandwidth |
|
Operating
Frequency |
2.4G
Hz, 5 GHz-1, 5 GHz-2 |
|
Ports |
RJ45
for 2.5G BaseT for WAN x 1, RJ45 for Gigabits BaseT for LAN x
3 |
|
USB
3.1 Gen 1 x 1 |
|
Button |
WPS
Button, Reset Button, Power Switch |
|
LED
Indicator |
Power
x 1 |
|
Power
Supply |
AC
Input : 110V~240V(50~60Hz) |
|
DC
Output : 19 V with max. 1.75 A current |
|
Package
content |
ZenWiFi
AX |
|
RJ-45
Cable |
|
Power
Adapter |
|
Quick
Start Guide |
|
Warranty
Card |
|
Product
Weight (g) |
716
g |
|
AiMesh |
AiMesh:Yes |
|
Primary
AiMesh router:Yes |
|
AiMesh
node:Yes |
|
Router
APP |
ASUS
Router APP:Yes |
|
Game |
Game
Boost/acceleration:No |
|
WTFast:No |
|
Alexa |
Support
Alexa skill:Yes |
|
IFTTT |
Support
IFTTT:Yes |
|
AiProtection |
AiProtection:AiProtection
Pro |
|
Malicious
site blocking:Yes |
|
Two-Way
IPS:Yes |
|
Infected
Device Prevention and Blocking:Yes |
|
Parental
Control |
Parental
Control:Yes |
|
Traffic
Control |
Adaptive
QoS:Yes |
|
Traffic
Monitor:Yes |
|
Traffic
Analyzer:Yes |
|
Wireless |
IPv6:Yes |
|
MU-MIMO:Yes |
|
Wi-Fi
Encryption:WPA2-PSK, WPA-PSK, WPA-Enterprise , WPA2-Enterprise , WPS
support |
|
UTF-8
SSID:Yes |
|
Guest
Network:Yes |
|
Maximum
Guest Network rule:Max 9 rules |
|
WPS:Yes |
|
Wi-Fi
MAC address filter:Yes |
|
Maximum
MAC filters:Max 64 rules |
|
Wireless
scheduler:Yes |
|
Airtime
fairness:Yes |
|
RADIUS
Server:Yes |
|
Universal
beamforming:Yes |
|
Explicit
beamforming:Yes |
|
WAN |
Dual
WAN:Yes |
|
WAN
Aggregation:No |
|
3G/4G
LTE dongle:Yes |
|
DMZ:Yes |
|
DDNS:Yes |
|
Let's
Encrypt:Yes |
|
LAN |
IGMP
snooping:Yes |
|
IPTV:Yes |
|
LAN
Link Aggregation:No |
|
VPN |
VPN
Client L2PT:Yes |
|
VPN
Client OVPN:Yes |
|
VPN
Client PPTP:Yes |
|
VPN
Server IPSec:Yes |
|
VPN
Server OVPN:Yes |
|
VPN
Server PPTP:Yes |
|
VPN
Fusion:No |
|
USB
application |
File
System:FS_Tuxera_HFS+, FS_Tuxera_NTFS, FS_Tuxera_vFAT, FS_ext2, FS_ext3,
FS_ext4 |
|
AiCloud:Yes |
|
Download
master:Yes |
|
AiDisk:Yes |
|
Media
Server:Yes |
|
Time
Machine:Yes |
|
Samba
Server:Yes |
|
FTP
Server:No |
|
Administration |
Operating
mode:Wireless router mode |
|
Range
extender mode |
|
Access
point mode |
|
Media
bridge mode |
|
Firewall:Yes |
|
Maximum
Firewall keyword filter:Max 64 rules |
|
Maximum
Firewall network service filter:Max 32 rules |
|
Maximum
Firewall URL filter:Max 64 rules |
|
Wake
on LAN (WOL):Yes |
|
Diagnosis
tools:Yes |
|
Feedback
system:Yes |
|
System
log:Yes |
