Warranty
Information |
|
Warranty |
2
Years |
Connector(s) |
|
1
- Connector Type(s) |
PCI
Express x4 |
1
- Internal Ports |
SATA
Power (15 pin) |
2
- External Ports |
USB
3.1 USB Type-A (9 pin, Gen 2, 10 Gbps) |
Environmental |
|
Operating
Temperature |
5C
to 50C (41F to 122F) |
Storage
Temperature |
-20C
to 60C (-4F to 140F) |
Humidity |
20~80%
RH |
Hardware |
|
Ports |
2 |
Interface |
USB
3.1 Gen 2 |
Bus
Type |
PCI
Express |
Card
Type |
Standard
Profile (LP bracket incl.) |
Port
Style |
Integrated
on Card |
Industry
Standards |
USB
3.1 Specification Rev. 1.0 |
USB
Specification Rev. 2.0 |
PCI
Express Base Specification Rev. 3.0 |
Intel
xHCI Specification Rev. 1.1 |
UASP
(USB Attached SCSI Protocol) Rev. 1.0 |
Chipset
ID |
ASMedia
- ASM2142 |
Packaging
Information |
|
Shipping
(Package) Weight |
4.4
oz [124.0 g] |
Package
Length |
6.8
in [17.2 cm] |
Package
Width |
5.6
in [14.2 cm] |
Package
Height |
1.2
in [30.0 mm] |
Performance |
|
Maximum
Data Transfer Rate |
10Gbps |
Type
and Rate |
USB
3.1 Gen 2 - 10 Gbit/s |
UASP
Support |
Yes |
Physical
Characteristics |
|
Product
Length |
3.7
in [95.0 mm] |
Product
Width |
0.5
in [12.0 mm] |
Product
Height |
2.8
in [70.0 mm] |
Weight
of Product |
1.8
oz [50.0 g] |
Software |
|
OS
Compatibility |
Windows
7, 8, 8.1, 10 |
Windows
Server 2008 R2, 2012, 2012 R2, 2016, 2019 |
Linux
3.5 to 4.11.x LTS version only |
Special
Notes / Requirements |
|
System
and Cable Requirements |
PCI
Express enabled computer or server with a PCI Express x4 slot or higher
(x8, x16) |
|
Optional
SATA power connector |
Note |
The
maximum throughput of this card is limited by the bus interface. PCI
Express Gen 1.0 max throughput is 2.5Gbps. PCI Express Gen 2.0 max
throughput is 5Gbps. PCI Express Gen 3.0 max throughput is
10Gbps. |
What's
in the Box |
|
1
- Included in Package |
USB
3.1 card |
|
low-profile
bracket |
|
quick-start
guide |
