GENERAL |
|
|
Phase |
Single
Phase |
|
Form
Factor |
Tower |
|
UPS
Topology |
Line-interactive |
|
Energy
Saving Technology |
GreenPower
UPS Bypass Technology |
|
INPUT |
|
|
Generator
Compatibility |
Yes |
|
Nominal
Input Voltage ( Vac ) |
230
10% |
|
Input
Voltage Range ( Vac ) |
167
~ 295 |
|
Input
Frequency ( Hz ) |
50
5 |
|
60
5 |
|
Input
Frequency Detection |
Auto-sensing |
|
Rated
Input Current ( A ) |
6.96 |
|
Input
Connector Type |
IEC
C14 |
|
Detachable
Power Cord Plug Type |
AU x 1 |
|
Power
Cord Length (ft.) |
5 |
|
Power
Cord Length (m.) |
1.5 |
|
OUTPUT |
|
|
Capacity
(VA) |
1600 |
|
Capacity
(Watts) |
960 |
|
On
Battery Waveform |
Simulated
Sine Wave |
|
On
Battery Voltage(s) ( Vac ) |
230
10% |
|
On
Battery Frequency ( Hz ) |
50
1% |
|
60
1% |
|
Automatic
Voltage Regulation (AVR) |
Single
Boost, Single Buck |
|
Overload
Protection |
Circuit
Breaker |
|
Outlet(s)
- Total |
4 |
|
Outlet
Type |
AU x 4 |
|
Outlet(s)
- Battery & Surge Protected |
3 |
|
Outlet(s)
- Surge-Only Protected |
1 |
|
Typical
Transfer Time ( ms ) |
4 |
|
BATTERY |
|
|
Runtime
at Half Load ( min ) |
11 |
|
Runtime
at Full Load ( min ) |
2 |
|
Typical
Recharge Time ( Hours ) |
8 |
|
Start
On Battery |
Yes |
|
User-replaceable |
No |
|
Battery
Type |
Sealed
Lead-acid |
|
SURGE
PROTECTION & FILTERING |
|
|
Surge
Suppression ( Joules ) |
450 |
|
EMI/RFI
Filtration |
Yes |
|
Phone/Network
Protection RJ11/RJ45 (Combo) |
1-in,
1-out |
|
MANAGEMENT
& COMMUNICATIONS |
|
|
LCD
Panel |
Yes |
|
LCD
Information Display |
Operation
Type, Power Status, Battery Status, Load Status, Fault & Warning,
Other Information |
|
LCD
Setting & Control |
Mode
Setting, Alarm Setting, Input & Output, Battery Setting, Fault &
Warning |
|
LED
Indicators |
Power
On |
|
HID
Compliant USB Port(s) |
1 |
|
Audible
Alarms |
Management
Cable ( pcs ) |
|
USB
Cable x1 |
|
Ethernet
Data Transmission Speed |
Power
Management Software |
|
PowerPanelPersonal
(Recommended) |
|
PHYSICAL |
|
|
Enclosure
Construction |
Plastic |
|
Color |
Black |
|
PHYSICAL
SIZE - UPS MODULE |
|
|
Dimensions
(WxHxD) (in.) |
3.9
x 11 x 14 |
|
Dimensions
(WxHxD) (mm.) |
100
x 281 x 355 |
|
Weight
(lbs.) |
22.97 |
|
Weight
(kg.) |
10.42 |
|
SHIPPING
DIMENSIONS |
|
|
Dimensions
(WxHxD) (in.) |
16.42
x 14.45 x 5.98 |
|
Dimensions
(WxHxD) (mm.) |
417
x 367 x 152 |
|
Weight
(lbs.) |
24.32 |
|
Weight
(kg.) |
11.03 |
|
ENVIRONMENTAL |
|
|
Operating
Temperature (F) |
32
~ 104 |
|
Operating
Temperature (C) |
0
~ 40 |
|
Operating
Relative Humidity
(Non-condensing) ( % ) |
0
~ 90 |
|
Operating
Elevation ( feet/meters ) |
0-9,843
feet (0-3,000 meters) |
|
Storage
Temperature (F) |
-4
~ 122 |
|
Storage
Temperature (C) |
-20
~ 50 |
|
Storage
Relative Humidity
(Non-condensing) ( % ) |
0
~ 90 |
|
Storage
Elevation ( feet/meters ) |
0-9,843
feet (0-3,000 meters) |
|
Online
Thermal Dissipation ( BTU/hr ) |
68 |
|
Audible
Noise at 1.0M from Surface of
Unit ( dBA ) |
50 |
|
CERTIFICATIONS |
|
|
Certifications |
CE,
RCM |
|
RoHS |
Yes |
|
WARRANTY |
|
|
Product
Warranty Period (Year) |
2 |
|
Battery
Warranty Period (Year) |
2 |
