GENERAL |
|
|
Phase |
Single
Phase |
|
Form
Factor |
Rackmount,
Tower |
|
UPS
Topology |
Online
Double Conversion |
|
Energy
Saving Technology |
Online
ECO Mode Efficiency > 97% |
|
Active
PFC Compatibility |
Yes |
|
INPUT |
|
|
Generator
Compatibility |
Yes |
|
Nominal
Input Voltage ( Vac ) |
200
2% |
|
208
2% |
|
220
2% |
|
230
2% |
|
240
2% |
|
Input
Voltage Range ( Vac ) |
200
~ 240 |
|
Adjustable
Voltage Range ( Vac ) |
0~25%
Load for 120 ~ 139 Vac |
|
0~50%
Load for 140 ~ 159 Vac |
|
0~75%
Load for 160 ~ 179 Vac |
|
0~100%
Load for 180 ~ 280 Vac |
|
Input
Frequency ( Hz ) |
50
10 |
|
60
10 |
|
Input
Frequency Detection |
Auto-sensing |
|
Rated
Input Current ( A ) |
32 |
|
Input
Power Factor |
0.99 |
|
Input
Connector Type |
Hardwire
Terminal Block |
|
OUTPUT |
|
|
Capacity
(VA) |
6000 |
|
Capacity
(Watts) |
6000 |
|
On
Battery Waveform |
Pure
Sine Wave |
|
On
Battery Voltage(s) ( Vac ) |
200
2% |
|
208
2% |
|
220
2% |
|
230
2% |
|
240
2% |
|
Output
Voltage Setting |
Configurable |
|
On
Battery Frequency ( Hz ) |
50
0.5% |
|
Output
Frequency Setting |
Configurable |
|
Power
Factor |
1 |
|
ECO
Mode Voltage Tolerance |
10
% |
|
Overload
Protection |
Internal
Current Limiting, Circuit Breaker |
|
Overload
Protection (Line Mode) |
105~125%
Load for 1 min, 125~150% Load for 10 sec |
|
Overload
Protection (Battery Mode) |
105~130%
Load for 10 sec, 130~150% Load for 2 sec |
|
Overload
Protection (Bypass Mode) |
Circuit
Breaker |
|
Crest
Factor |
3:01 |
|
Harmonic
Distortion (Linear Load) |
THD3% |
|
Harmonic
Distortion (Non-linear Load) |
THD5% |
|
Internal
Bypass |
Automatic
Bypass, Manual Bypass |
|
Outlet(s)
- Total |
7 |
|
Outlet
Type |
IEC
C13 x 4 |
|
IEC
C19 x 2 |
|
Hardwire
Terminal Block x 1 |
|
Outlet(s)
- Battery & Surge Protected |
7 |
|
Outlet(s)
- Critical Load (CL) |
4 |
|
Outlet(s)
- Non-Critical Load (NCL) |
3 |
|
Typical
Transfer Time ( ms ) |
0 |
|
BATTERY |
|
|
Runtime
at Half Load ( min ) |
4.9 |
|
Runtime
at Full Load ( min ) |
1.4 |
|
Typical
Recharge Time ( Hours ) |
4 |
|
Start
On Battery |
Yes |
|
Smart
Battery Management (SBM) |
Yes |
|
Built-in
Battery Management Module |
Yes |
|
User-replaceable |
Yes
- Qualified Personnel Only |
|
Hot-swappable |
Yes |
|
Battery
Type |
Sealed
Lead-acid |
|
Replacement
Battery Pack |
RBP0144 |
|
RBP
Quantity ( pcs ) |
1 |
|
Battery
Quantity (Each RBP) ( pcs ) |
12 |
|
Battery
Voltage (Each RBP) ( V ) |
144 |
|
Compatible
Extended Battery Module (EBM) |
BPE144VL2U01
(Built-in Charger) |
|
Max.
EBM Quantity ( pcs ) |
10 |
|
SURGE
PROTECTION & FILTERING |
|
|
Surge
Suppression ( Joules ) |
2430 |
|
EMI/RFI
Filtration |
Yes |
|
MANAGEMENT
& COMMUNICATIONS |
|
|
LCD
Panel |
Yes |
|
LCD
Types |
Color
LCD |
|
LCD
Orientation |
Rotatable
LCD Automatic, Rotatable LCD via Setting |
|
Tiltable
LCD Panel |
18 |
|
LCD
Information Display |
Operation
Type, Power Status, Battery Status, Load Status, Fault & Warning,
Other Information, Event & Log |
|
LCD
Setting & Control |
Mode
Setting, Alarm Setting, Input & Output, Battery Setting, Fault &
Warning, Communication, Event & Log, Security Setting,
Language |
|
LED
Indicators |
Power
On |
|
HID
Compliant USB Port(s) |
1 |
|
Emergency
Power Off (EPO) Port |
Yes |
|
Audible
Alarms |
Battery
Mode, Low Battery, Overload, Overcharge, Overheat, UPS Fault, Replace
Battery |
|
Management
Cable ( pcs ) |
USB
Cable x1, Serial Cable x1 |
|
Power
Management Software |
PowerPanel
Business (Recommended) |
|
SNMP/HTTP
Remote Monitoring |
Yes
- RMCARD205 included |
|
PHYSICAL |
|
|
Enclosure
Construction |
Metal |
|
Color |
Black |
|
Rackmount
Rail |
Yes |
|
Rackmount
Ears |
Yes |
|
High
Density Design |
Yes |
|
PHYSICAL
SIZE - UPS MODULE |
|
|
Dimensions
(WxHxD) (in.) |
17
x 3.4 x 28.3 |
|
Dimensions
(WxHxD) (mm.) |
433
x 86.5 x 720 |
|
Rack-mounted
Dimensions (WxHxD) (in.) |
17 x 3.4 x 27 *Without
the dimension of front panel |
|
Rack-mounted
Dimensions (WxHxD) (mm.) |
433 x 86.5 x 685 *Without
the dimension of front panel |
|
Weight
(lbs.) |
92.4 |
|
Weight
(kg.) |
42 |
|
Installed
Rack Height ( U ) |
2 |
|
SHIPPING
DIMENSIONS |
|
|
Dimensions
(WxHxD) (in.) |
23.6
x 13.2 x 43.3 |
|
Dimensions
(WxHxD) (mm.) |
600
x 335 x 1100 |
|
Weight
(lbs.) |
114.6 |
|
Weight
(kg.) |
52.1 |
|
ENVIRONMENTAL |
|
|
Operating
Temperature (F) |
32
~ 104 |
|
Operating
Temperature (C) |
0
~ 40 |
|
Operating
Relative Humidity
(Non-condensing) ( % ) |
0
~ 90 |
|
Operating
Elevation ( feet/meters ) |
0-9,843
feet (0-3,000 meters) |
|
Storage
Temperature (F) |
23
~ 113 |
|
Storage
Temperature (C) |
-5
~ 45 |
|
Storage
Relative Humidity
(Non-condensing) ( % ) |
0
~ 95 |
|
Storage
Elevation ( feet/meters ) |
0-14,764
feet (0-4,500 meters) |
|
Online
Thermal Dissipation ( BTU/hr ) |
1613 |
|
Audible
Noise at 1.0M from Surface of Unit |
43~66
dBA (0~100 % load) |
|
CERTIFICATIONS |
|
|
Certifications |
CE,
EAC, RCM |
|
RoHS |
Yes |
