Output |
|
Output
power capacity |
600Watt/
1200VA |
|
Max
Configurable Power (Watts) |
600Watts
/ 1200VA |
|
Nominal
Output Voltage |
230V |
|
Output
Voltage Distortion |
Less
than 5% at full load |
|
Output
Frequency (sync to mains) |
47
53 Hz for 50 Hz nominal, 57 63 Hz for 60 Hz
nominal |
|
Topology |
Line
Interactive |
|
Output
Connections |
(4)
Australian 3 pin 10Amp |
|
Transfer
Time |
2-4ms
typical |
|
Input |
|
|
Nominal
Input Voltage |
230V |
|
Input
frequency |
50/60
Hz +/- 3 Hz (auto sensing) |
|
Input
Connections |
2m
IEC to Australian 3 pin plug |
|
Input
voltage range for main operations |
170
280V |
|
Batteries
& Runtime |
|
Battery
type |
Maintenance-free
sealed Lead-Acid battery with suspended electrolyte :
leakproof |
|
Typical
recharge time |
3
hour(s) |
|
Expected
Battery Life (years) |
3-
5 years |
|
Communications
& Management |
|
Interface
Port(s) |
USB |
|
Control
panel |
LCD
status display with On Line : On Battery : Replace Battery and Overload
indicators |
|
Audible
Alarm |
Alarm
when on battery : distinctive low battery alarm : overload continuous tone
alarm |
|
Surge
Protection and Filtering |
|
Surge
energy rating |
320Joules |
|
Data
Line Protection |
RJ-11
Surge Protection |
|
Physical |
|
Maximum
Height |
195mm |
|
Maximum
Width |
139mm |
|
Maximum
Depth |
364mm |
|
Net
Weight |
8.9kg |
|
Shipping
Weight |
10kg |
|
Shipping
Height |
220mm |
|
Shipping
Width |
140mm |
|
Shipping
Depth |
340mm |
|
Color |
Black |
|
Environmental |
|
Operating
Environment |
0
40 C |
|
Operating
Relative Humidity |
0
95 % |
|
Operating
Elevation |
0-3000meters |
|
Storage
Temperature |
-15
45 C |
|
Storage
Relative Humidity |
0
95 % |
|
Storage
Elevation |
0-15000meters |
|
Audible
noise at 1 meter from surface of unit |
45.0dBA |
|
Conformance |
|
Approvals |
CE |
|
Standard
warranty |
3
Year Advance Replacement* |
