GENERAL |
|
|
Input
DC Voltage Range ( Vdc ) |
15
~ 60 |
|
Power
Consumption ( W ) |
4 |
|
Number
of Monitored Strings ( PCS ) |
4 |
|
Number
of String Batteries ( PCS ) |
120 |
|
Number
of Monitored Batteries ( PCS ) |
480 |
|
MANAGEMENT
& COMMUNICATIONS |
|
|
LCD
Panel |
Yes |
|
LED
Indicators |
System,
ENV, Battery Status, String Status, Battery
Balance |
|
Connection
Ports to Battery Probes |
Yes
- via RJ25 |
|
Network
Port |
RJ45
- 10/100Mbps Ethernet |
|
RS485
Port |
Yes
- MODBUS RTU |
|
Supported
Protocols |
IPv4/v6,
SNMPv1/v3, HTTP/HTTPs, TCP/IP, UDP, DHCP, NTP, DNS, SMTP, SSH, SSL, TLS
1.2, Telnet, FTP, MODBUS TCP and Syslog |
|
Authentication |
RADIUS,
LDAP, LDAPS, Windows AD |
|
User-upgradeable
Firmware |
Yes |
|
Environmental
Sensor Supported |
Yes |
|
BMS
Software Supported |
Yes |
|
PHYSICAL |
|
|
Form
Factor |
Desktop |
|
Enclosure
Construction |
Metal |
|
Color |
Black |
|
PHYSICAL
SIZE |
|
|
Dimensions
(WxHxD) (in.) |
8.27
x 1.14 x 3.94 |
|
Dimensions
(WxHxD) (mm.) |
210
x 29 x 100 |
|
Weight
(lbs.) |
1.26 |
|
Weight
(kg.) |
0.573 |
|
Installed
Rack Height ( U ) |
0 |
|
SHIPPING
DIMENSIONS |
|
|
Dimensions
(WxHxD) (mm.) |
247
x 75 x 149 |
|
Dimensions
(WxHxD) (in.) |
9.72
x 2.95 x 5.87 |
|
Weight
(lbs.) |
2.13 |
|
Weight
(kg.) |
0.967 |
|
ENVIRONMENTAL |
|
|
Operating
Temperature (F) |
-40
~ 140 |
|
Operating
Temperature (C) |
-40
~ 60 |
|
Operating
Relative Humidity
(Non-condensing) ( % ) |
0
~ 90 |
|
Operating
Elevation |
0-9,843
feet (0-3,000 meters) |
|
Storage
Temperature (F) |
-40
~ 149 |
|
Storage
Temperature (C) |
-40
~ 65 |
|
Storage
Relative Humidity
(Non-condensing) ( % ) |
0
~ 90 |
|
Storage
Elevation |
0-9,843
feet (0-3,000 meters) |
|
CERTIFICATIONS |
|
|
Certifications |
CE,
FCC Class A |
|
RoHS |
Yes |
|
WARRANTY |
|
|
Product
Warranty Period (Year) |
2 |
|
Battery
Warranty Period (Year) |
2 |
