| Display |
|---|
| Display diagonal | 2.34 m (92") |
| Working area | 2141.92 x 903.63 mm |
| Contrast ratio (typical) | 5000:1 |
| Touchscreen | Yes |
| Accuracy touch | 1 mm |
| Touchscreen type | Infrared |
| Number of simultaneous touchpoints | 50 |
| Touch resolution | 32767 x 32768 pixels |
| Touch system response time | 5 ms |
| Panel type | LCD |
| Viewing angle, vertical | 178° |
| Viewing angle, horizontal | 178° |
| Response time | 6.5 ms |
| Colour gamut | 90% |
| Screen glass thickness | 3 mm |
| Display brightness | 450 cd/m² |
| Display resolution | 5120 x 2160 pixels |
| Display number of colours | 1.07 billion colours |
| HD type | 5K Ultra HD |
| LED backlighting type | Direct-LED |
| Maximum refresh rate | 60 Hz |
| Anti-glare screen | Yes |
| Surface material | Tempered glass |
| Native aspect ratio | 21:9 |
| Pen & touch differentiation | Yes |
| Palm rejection | Yes |
| LED backlight | Yes |
| Features |
|---|
| Display diagonal | 2.34 m (92") |
| Working area | 2141.92 x 903.63 mm |
| Contrast ratio (typical) | 5000:1 |
| Touchscreen | Yes |
| Accuracy touch | 1 mm |
| Touchscreen type | Infrared |
| Number of simultaneous touchpoints | 50 |
| Touch resolution | 32767 x 32768 pixels |
| Touch system response time | 5 ms |
| Panel type | LCD |
| Viewing angle, vertical | 178° |
| Viewing angle, horizontal | 178° |
| Response time | 6.5 ms |
| Colour gamut | 90% |
| Screen glass thickness | 3 mm |
| Display brightness | 450 cd/m² |
| Display resolution | 5120 x 2160 pixels |
| Display number of colours | 1.07 billion colours |
| HD type | 5K Ultra HD |
| LED backlighting type | Direct-LED |
| Maximum refresh rate | 60 Hz |
| Anti-glare screen | Yes |
| Surface material | Tempered glass |
| Native aspect ratio | 21:9 |
| Pen & touch differentiation | Yes |
| Palm rejection | Yes |
| LED backlight | Yes |
| Product colour | Black, Grey |
| Operating system installed | Android |
| Computer system |
|---|
| Operating system installed | Android |
| Built-in processor | Yes |
| Processor cores | 4 |
| RAM capacity | 8 GB |
| Operating system version | 13 |
| Audio |
|---|
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 2 |
| Speaker power | 40 W |
| Built-in subwoofer | Yes |
| Subwoofer RMS power | 15 W |
| Number of microphone arrays | 8 |
| Built-in microphone | Yes |
| Network |
|---|
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 6 (802.11ax) |
| Wake-on-LAN ready | Yes |
| Ports & interfaces |
|---|
| USB 2.0 ports quantity | 1 |
| HDMI ports quantity | 5 |
| Ethernet LAN (RJ-45) ports | 2 |
| Microphone connectivity | 3.5 mm |
| Headphone connectivity | 3.5 mm |
| RS-232 ports | 1 |
| USB Type-C ports quantity | 2 |
| HDMI output ports quantity | 1 |
| DisplayPorts quantity | 1 |
| S/PDIF out port | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 6 |
| Audio output | 1 |
| USB Power Delivery up to | 100 W |
| USB Power Delivery | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-B Touch ports quantity | 3 |
| OPS slot | 1 |
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
| Wi-Fi | Yes |
| Ergonomics |
|---|
| Wall mountable | Yes |
| Product colour | Black, Grey |
| Panel mounting interface | 800 x 600 mm |
| VESA mounting | Yes |
| Frame material | Aluminium |
| Power |
|---|
| AC input voltage | 240 V |
| Power consumption (typical) | 330 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (max) | 800 W |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -20 - 60 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Performance |
|---|
| Remote control included | Yes |
| Technical details |
|---|
| Working area | 2141.92 x 903.63 mm |
| Touchscreen | Yes |
| Remote control included | Yes |
| Accuracy touch | 1 mm |
| Panel type | LCD |
| Viewing angle, vertical | 178° |
| Viewing angle, horizontal | 178° |
| Response time | 6.5 ms |
| Colour gamut | 90% |
| Quantity per pack | 1 pc(s) |
| Weight & dimensions |
|---|
| Width | 2203 mm |
| Depth | 89 mm |
| Height | 1000 mm |
| Weight | 67.6 kg |
| Packaging data |
|---|
| Package width | 2360 mm |
| Package depth | 1140 mm |
| Package height | 225 mm |
| Package weight | 88.5 kg |
| Quantity per pack | 1 pc(s) |
| Stylus included | Yes |
| Projector |
|---|
| Contrast ratio (typical) | 5000:1 |
| Packaging content |
|---|
| Cables included | HDMI, Power, USB Type-A to USB Type-B, USB Type-C |
| Stylus included | Yes |
| Mounting kit | Yes |
| Remote control included | Yes |
| Batteries included | Yes |
| Eraser included | Yes |
| Processor |
|---|
| Built-in processor | Yes |
| Processor cores | 4 |
| Memory |
|---|
| RAM capacity | 8 GB |
| Colour |
|---|
| Product colour | Black, Grey |
