GPU Features
Unified Driver Architecture
(UDA)
The
NVIDIA UDA guarantees forward and backward compatibility with software
drivers. Simplifies upgrading to a new solution because all Quadro
products work with the same driver software.
Hardware 3D Window Clipping
Hardware accelerated clip regions (data
transfer mechanism between a window and the frame buffer) improve overall
graphics performance by increasing transfer speed between color buffer and
frame buffer.
Display Features
High-Quality Display
Connectivity
Drives ultra-high-resolution panels, producing
phenomenal image quality. Support two active connectors including,
dual-link DVI with up to 3840 x 2400 @ 24Hz on each panel, DisplayPort
with up to up to 2560 x 1600, or HDMI for integrated audio and video thru
the GPU.
30-Bit Color Fidelity
30-bit
color fidelity (10-bits per color) enables billions of color variations
for rich, vivid image quality with the broadest dynamic range.
3D Vision and 3D Vision
Pro
Advanced active shutter glasses deliver crystal-clear
stereoscopic 3D visualization for the most immersive experience. Infrared
(3D Vision) or RF (3D Vision Pro) technology enables a range of immersive
environments ranging from your desktop workstation to collaborative work
spaces. 3D Vision and 3D Vision Pro sold separately.
OpenGL Quad Buffered Stereo Support
OpenGL Quad Buffered Stereo offers professional applications
the capability of smooth and immersive 3D Stereo experience.
Software Support
CUDA Parallel Computing
Architecture
NVIDIA Quadro solutions leverage general purpose
GPU computing using standard programming languages like C/C++ and Fortran,
and emerging APIs such as OpenCL and Direct Compute. This broad
adoption of CUDA is accelerating techniques like ray tracing, video and
image processing, and computation fluid dynamics.
Cg Programming
Programmable GPU
leverages Cg high-level, open-standard shading language to enable the
creation and integration of real-time photorealistic effects into 3D
models, scenes and designs.
Microsoft Windows 7 Support
Take
advantage of all the new and compelling features included with Windows
7, delivering unprecedented application performance, advanced visual
realism, and premium reliability with superior application compatibility
on mobile and desktop workstations.
NVIDIA Graphics API Extensions
NVIDIA provides a set of extensions to standard graphics APIs
for Linux and Windows, enabling applications to take maximum advantage of
state-of-the-art GPU capabilities.
NVIDIA® Application Acceleration Engines
Support
Supercharge application performance and capabilities
with highly optimized software modules, including SceniX and OptiX for
advanced creative and investigative possibilities.
NVIDIA Mosaic Technology
NVIDIA®
Mosaic Technology enables transparent scaling of any application across up
to eight displays, using multiple graphics solutions.
nView® Advanced Desktop
Software
The nView® Advanced Desktop Software delivers maximum
flexibility for single large display or multi-display options, providing
unprecedented end-user control of the desktop experience for increased
productivity.
Industry Standard
Compatible with Industry Standard
Architectures
Compatible with Microsoft and Linux operating
systems, as well as Intel and AMD x86 32- and 64-bit microprocessor
architectures.
PCI Express 2.0
Compliant
Doubles the data transfer rate up to 5 GT/sec
per lane for an aggregate bandwidth of 16 GB/sec bi-directional (8 GB/sec
in each direction).
Ultra-Quiet Design
Acoustics
lower than 28db for an ultra-quiet desktop
environment. |
