| GENERAL |
| Device Type |
Switch - 20 ports - Managed |
| Enclosure Type |
DIN rail mountable |
| Subtype |
Gigabit Ethernet |
| Ports |
16 x 10/100 + 2 x combo Gigabit SFP + 2 x Fast Ethernet SFP |
| Performance |
Forwarding performance (64-byte packet size): 6.5 Mpps |
| Capacity |
Virtual interfaces (VLANs): 255 |
| MAC Address Table Size |
8K entries |
| Routing Protocol |
IGMP, static IPv4 routing |
| Remote Management Protocol |
SNMP 3, HTTPS, SSH |
| Authentication Method |
Secure Shell (SSH), RADIUS, TACACS+ |
| Features |
DHCP support, Broadcast Storm Control, Multicast Storm Control,
Unicast Storm Control, Spanning Tree Protocol (STP) support, Rapid
Spanning Tree Protocol (RSTP) support, Quality of Service (QoS), Port
Security, Remote Switch Port Analyzer (RSPAN) |
| Compliant Standards |
IEEE 802.1x |
| RAM |
256 MB |
| Flash Memory |
64 MB |
| EXPANSION / CONNECTIVITY |
| Interfaces |
16 x 100Base-TX RJ-45 2 x 1000Base-T RJ-45 4 x SFP (mini-GBIC) |
| Expansion Slots |
1 (total) / 1 (free) x SD Memory Card |
| MISCELLANEOUS |
| Rack Mounting Kit |
Optional |
| MTBF |
374,052 hours |
| Compliant Standards |
C-Tick, CISPR 22 Class A, CISPR 24, IEC 61000-4-11, VCCI Class A ITE,
EN55022 Class A, EN 61000-6-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3,
EN 61000-4-6, ICES-003 Class A, EN 61000-4-5, RoHS, FCC CFR47 Part 15, EN
61000-4-8, UL 60950-1, IEC 60950-1, EN 60950-1, EN 61000-6-4, IEC
60068-2-30, KCC, IEC 60068-2-27, IEC 60068-2-6, UL 508, FCC Part 15 A, IEC
60529 IP30, CISPR 11, CSA 22.2 No. 142, EN 61131-2, EN 61326-1, EN
61000-4-9, EN 61000-4-29, IEC 60068-2-14 |
| SOFTWARE / SYSTEM REQUIREMENTS |
| Software Included |
Cisco IOS LAN Base |
| DIMENSIONS & WEIGHT |
| Width |
7.37 cm |
| Depth |
11.46 cm |
| Height |
12.7 cm |
| Weight |
1.11 kg |
| MANUFACTURER WARRANTY |
| Service & Support |
Limited warranty - 1 year |
| ENVIRONMENTAL PARAMETERS |
| Humidity Range Operating |
5 - 95% (non-condensing) |
| Min Storage Temperature |
-40 C |
| Max Storage Temperature |
85 C |
