PANEL |
|
Display Type |
Digital Media Players |
|
|
COMPATIBLE MODEL |
|
Compatible Models |
84WS70MS-B, 84WS70BS-B |
|
|
GENERAL SPECIFICATIONS |
|
CPU |
Intel® CoreTM i7-3610QE 2.3 GHz (Qual Core) |
Storage |
2.5" 1TB HDD |
Weight |
5.3 Ibs |
O/S |
Windows Embedded Standard 7 Professional (64bit) |
Main Memory |
DDR3 1333 4GB (2 SODIMM) |
Dimensions (W x H x D) |
10.2” x 1.6” x 10.9” |
Chip Set |
Mobile Intel® QM77 |
Carton Dimension (W x H x D) |
13.1” x 3.9” x 13.6” (Set Box) |
Graphic |
AMD Radeon™ E6760 with 1GB VRAM |
Graphic Performance |
Full HD x 4, Ultra HD x 1 Decoding |
|
|
MULTI I/O PORT |
|
Display Out |
DP x 4 / RGB |
LAN Port |
Intel 82577LM Gigabit(10/100/1,000 Mbps) Ethernet
PHY |
Mini PCI Express Socket |
Supported |
LINE Out |
Supported |
Serial Port |
Supported |
USB Port |
Hi-Speed USB 2.0 x 2 , USB 3.0 Port x 1 |
|
|
OPERATIONAL SPECIFICATION |
|
Resolution (DP) |
Maximum Resolution 2,048 x 1,536 @ 75 Hz |
Resolution (RGB) |
Maximum Resolution 1,920 x 1,080 @ 75 Hz |
Resolution (DP with HBR2) |
Maximum Resolution 3,840 x 2,160 @ 30 Hz |
Operating Conditions |
Operating Temperature 5°C to 40°C Operating Humidity 10% to 80%;
Storage Temperature -20°C to 60°C; Storage Humidity 5% to
95% |
Power |
Rated Voltage AC 100-240V~, 50/60 Hz,
1.8A |
