Gigabyte N166TOC-6GD GeForce GTX 1660 Ti OC 6G Graphics Card



Features

  • Powered by GeForce® GTX 1660 Ti
  • Integrated with 6GB GDDR6 192-bit memory interface
  • WINDFORCE 3X Cooling System with alternate spinning fans
  • RGB Fusion 2.0 – synchronize with other AORUS devices
  • Protection back plate

Overview

WINDFORCE 3X COOLING SYSTEM

The WINDFORCE 3X cooling system features 3x 80mm unique blade fans, alternate spinning fan, 3 composite copper heat pipes, heat-pipe direct touch and 3D active fan functionality, together delivering an effective heat dissipation capacity for higher performance at lower temperatures.

ALTERNATE SPINNING

The GIGABYTE patent “Alternate Spinning” is the only solution that can solve the turbulent airflow of three fans. The biggest problem with the three fans is turbulence. Since the fans rotate in the same direction, the airflow direction is opposite between the fans, which will cause turbulent airflow and reduce heat dissipation efficiency. GIGABYTE turns the middle fan in the opposite direction, so that the airflow direction between the two fans is the same, reducing the turbulence and enhancing the airflow pressure.

UNIQUE BLADE FAN

The airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface, effectively enhancing the airflow.

3D ACTIVE FAN

The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game. It allows gamers to enjoy gameplay in complete silence when the system is running light or idle.

HEAT PIPES DIRECT TOUCH GPU

The shape of the pure copper heat pipes maximizes the direct contact area with the GPU, enhancing heat transfer. The heat pipes also cover the VRAM through a large metal plate contact to ensure proper cooling.

COMPOSITE HEAT-PIPE

The composite heat-pipe combines thermal conductivity and phase transition to efficiently manage the heat transfer between two solid interfaces which increases cooling capacity.

GAME IN STYLE

RGB FUSION 2.0

With 16.7M customizable color options and numerous lighting effects, you can choose lighting effects or synchronize with other AORUS devices.

CYCLING

Smoothly cycles through all colors

CONSISTENT

Choose a color for static light

FLASH

Choose a color for flash effect

DUAL FLASH

Choose a color for double flash effect

BREATHING

Choose a color to fade in and out

BUILT STRONG

EXTREME DURABILITY AND OVERCLOCKING

The graphics card uses the 4+2 power phase design to allow the MOSFET to operate at lower temperature, and over-temperature protection design and load balancing for each MOSFET, plus the Ultra Durable certified chokes and capacitors, to provide excellent performance and longer system life.

PROTECTION BACK PLATE

The back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete protection.

IN TOTAL COMMAND

The interface and functionality of the software is subject to each model.

AORUS ENGINE

The cutting edge intuitive interface allows you to adjust the clock speed, voltage, fan performance and power target in real-time according to your games requirements.

Specifications

Graphics Processing

GeForce® GTX 1660 Ti

Core Clock

1860 MHz (Reference card is 1770 MHz)

CUDA® Cores

1536

Memory Clock

12000 MHz

Memory Size

6 GB

Memory Type

GDDR6

Memory Bus

192 bit

Memory Bandwidth (GB/sec)

288 GB/s

Card Bus

PCI-E 3.0 x 16

Digital max resolution

[email protected]

Multi-view

4

Card size

L=280 W=116.7 H=40.4 mm

PCB Form

ATX

DirectX

12

OpenGL

4.5

Recommended PSU

450W

Power Connectors

8 Pin*1

Output

DisplayPort 1.4 *3 (Max Resolution: 4096x2160 @60 Hz)

HDMI 2.0b *1 (Max Resolution: 7680x4320 @60 Hz)

SLI support

No

Accessories

1. Quick guide

2. Driver CD

No additional files, specification sheets, guides or documentation found for product.

Warranty: 36

Full manufacturers warranty details are available at the manufacturers (Gigabyte) web site.
