DISPLAY |
|
|
Diagonal
Size |
74.6" |
|
Type |
Edge
LED |
|
Resolution |
3,840
x 2,160 (4K UHD) |
|
Brightness |
400cd/m2 |
|
Dynamic
Contrast Ratio |
1,000,000:1 |
|
Static
(Panel) Contrast Ratio |
1,200:1 |
|
Viewing
Angle Degree |
178°
/ 178° |
|
Response
Time (G to G) |
8 |
|
Frame
Rate |
T120 |
|
BROADCASTING
SYSTEM |
|
|
Analog |
NTSC |
|
Digital |
ATSC
/ VSB / Clear QAM |
|
VIDEO |
|
|
XD
Engine |
Yes |
|
Real
Cinema 24p (3:3 pull down) |
Yes |
|
Aspect
Ratio |
6
modes (16:9, Original, 4:3, Vertical Zoom, All-Direction Zoom, Just
Scan) |
|
AUDIO |
|
|
Audio
Output / Speaker System |
10W
+ 10W / 2.0 ch |
|
Sound
Mode |
6
modes (Standard, Cinema, Clear Voice III, Sports, Music,
Game) |
|
Clear
Voice |
Yes |
|
GENERAL
FEATURES |
|
|
Installation |
USB
Cloning |
|
Management |
WOL,
SNMP, Self Diagnostics via USB, Multi IR Code, HTNG/HDMI-CEC* *HDMI-CEC :
Compatibility can differ by equipment. |
|
USB |
Moving
Picture Playback (.asf, .wmv, .avi, .mp4, .m4v, .mov, .3gp, .3g2, .mkv,
.mpg, .mpeg, .dat, etc.), Picture (jpeg, jpg, jpe, BMP, PNG), Audio Codec
(.mp3, .wav, .OGG, .WMA, .flac) |
|
Setting
Option |
Auto
Off / Sleep Timer, Smart Energy Saving, Motion Eye
Care |
|
HOSPITALITY
FEATURES |
|
|
Yes |
PDM
(Public Display Mode), Lock Mode, Welcome Screen (Splash Image), Insert
Image, External Speaker Out, RJP Compatibility, Crestron® Connected
Certified, Time Scheduler |
|
INTERFACE |
|
|
Side |
HDMI
In (2) |
|
Rear |
RF
In, AV In (Sharing with Component In), Component In + Video, Optical
Digital Audio Out, HDMI In, RS-232C In, RJ45 (SNMP), External Speaker
Out |
|
DIMENSION |
|
|
Bezel
Width (L/R, U, B) : on bezel based (mm) |
14.7,
14.7, 14.7 |
|
Bezel
Width (L/R, U, B) : off bezel based (mm) |
12.7,
12.7, 12.7 |
|
Vesa
(mm) |
600
x 400 |
|
WxHxD
/ weight (without stand) |
66.8"
x 38.6" x 1.5" / 91.1lb |
|
WxHxD
/ weight (with stand) |
66.8"
x 41.4" x 11.7" / 92.6lb |
|
WxHxD
/ weight (Carton) |
72.4"
x 46.0" x 9.1" / 116.8lb |
|
POWER |
|
|
Voltage,
Hz |
100
~ 240V, 50/60Hz |
|
Typical
(Watts) |
86.8 |
|
Stand-by
(Watts) |
0.5↓ |
|
STANDARD
APPROVAL |
|
|
Safety |
UL |
|
Environment |
FCC |
|
Etc. |
RoHS,
UL, NOM, ENERGY STAR® Qualified |
|
UPC |
|
|
75UV340C |
7.19193E+11 |
