All stock codes associated to this product
65EV5E
LG 65EV5E 65" Monitor
Features
- Brightness(Typ.): 400 cd/m² (APL 25%)
- Bezel: 1.2 mm (Even, Off bezel)
- Depth: 7.9 mm (Head)
- Interface: HDMI/ DP/ USB 2.0(2)/ RS232C/ RJ45/ Audio Out/ IR
Overview
Artistic Space beyond Display, Video Wall OLED Signage
This video wall OLED signage delivers the deepest black against which colors
come alive, maximizing the impact of advertising with lifelike content playback.
Users can expand the size of the screen as much as they want by tiling up
displays horizontally.
Unrivaled Picture Quality
Perfect Color
Unrivaled Picture Quality
Perfect Color
Accurate & stable color reproduction
Self-lighting pixels bring colors to life with superb accuracy.
Unrivaled Picture Quality
Perfect Viewing Screen
Wide viewing angle
LG OLED Signage delivers awe-inspiring picture quality across the entire
screen, even from wide viewing angles.
Ultimate Elegance of the Design
Sleek & Slim Depth
LG’s OLED technology unlocks the new worlds of design flexibility with
unbelievably slim display. The advantages the OLED display brings are countless
from the easier installation to a sleek look.
Ultimate Elegance of the Design
One Perfect Look with Minimized Seam
Minimized seams makes connected displays appear like a single perfect screen,
reducing bezel visibility and enhancing immersion.
Truly Immersive Screen
1×N Expandable Screen Size
By tiling up displays horizontally*, the screen size can be as large as users
want. Expansive, large screens are more effective at moving viewers by providing
an incredibly immersive viewing experience.
Truly Immersive Screen
Uniform Brightness with VLC
VLC (Video wall Luminance Compensation) allows the tiled displays to deliver
consistent picture quality throughout the screen by adjusting the luminance
value of different tiles so that they appear as a uniform whole.
Operational Efficiency
Easy Content Management
The embedded CMS(Content Management System) allows you to create and edit
content using internal/external sources as well as set playlists to play at the
desired schedule without the need for a separate PC. Thanks to the intuitive GUI
and a menu structure based on usage scenarios, content management has been made
much easier.
Operational Efficiency
LAN Daisy Chain Management
A LAN daisy chain allows you to execute commands to control and monitor the
screens and even update their firmware.
Specifications
|
Panel |
|
|
Screen
Size |
65" |
|
Resolution |
3,840
x 2,160 (UHD) |
|
Brightness
(APL25%, Typ., cd/m²) |
400 |
|
Brigthness(APL100%,
Typ., cd/m²) |
150 |
|
|
|
|
Connectivity |
|
|
Input |
HDMI,
DP, USB 2.0 (2) |
|
Output |
DP,
Audio |
|
External
Control |
RS232C
In/out, RJ45 (LAN) In/out, IR In |
|
|
|
|
Physical
Specification |
|
|
Bezel
Width |
1.2mm
(Even) *Off-Bezel |
|
|
9.1
mm (T/B), 8.7 mm (L), 11.6 mm (R) *On-Bezel |
|
|
6.7
mm (Seam) |
|
Dimension
(W x H x D) |
1,634.6
x 1,446.7 x 7.9 mm (Head 1x2) |
|
|
2,445.4
x 1,446.7 x 7.9 mm (Head 1x3) |
|
|
782.8
x 35.5 x 239.0 mm (Signage Box) |
|
Weight |
29.4
kg (Set 1×2) / 44.5 kg (Set 1×3) |
|
Carton
Dimensions (W x H x D) |
1,940
x 1,120 x 536 mm (Set 1x2) / 1,940 x 1,120 x 646 mm (Set
1x3) |
|
Packed
Weight |
69.6
kg (Set 1x2, w/ Pallet) / 96 kg (Set 1x3, w/ Pallet) |
|
|
|
|
Environment
Conditions |
|
|
Operation
Temperature |
0°C
~40°C |
|
Operation
Humidity |
10%
~ 80% |
|
|
|
|
Power |
|
|
Power
Supply |
100-240V~,
50/60Hz |
|
Power
Type |
Built-In
Power |
|
|
|
|
Power
Consumption |
|
|
Typ. |
440
W *8 Color Bar Based |
|
Max |
478
W *8 Color Bar Based |
|
|
|
|
Standard
(Certification) |
|
|
Safety |
IEC
60950-1 / EN 60950-1 / UL 60950-1 |
|
EMC |
FCC
Class "A" / CE / KC |
|
ErP
/ Energy Star |
Yes
/ No |
|
|
|
|
Media
Player Compatibility |
|
|
OPS
Type Compatible |
No |
|
External
Media player Attatchable |
Yes |
|
|
|
|
Software
Compatibility |
|
|
Content
Management Software |
SuperSign
CMS |
|
Control
and Monitoring Software |
SuperSign
Control+ / Control |
|
|
|
|
Accessory |
|
|
Basic |
Remote
Controller, Power Cord, QSG, IR Receiver, Regulation Book, Phone to RS232C
Gender, RS232 Cable (4p-4p), FFC Cables (for Connection Between Panel and
Signage Box), DP Cable, LAN Cable, LC (VLC Cable), Fixer Screws, Anchor
Bolts, Polyester Tapes, Panel
Jigs |
