| Specifications |
|---|
| Audio | Realtek® Audio CODEC High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out |
| Chipset | AMD B450 |
| Form Factor | ATX Form Factor; 30.5cm x 23.5cm |
| I/O Connectors | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 2 x M.2 Socket 3 connectors 6 x SATA 6Gb/s connectors 1 x CPU fan header 3 x system fan headers 1 x CPU cooler LED strip/RGB LED strip extension cable header 1 x RGB (RGBW) LED strip header 2 x digital LED strip headers 2 x digital LED strip power select jumpers 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x USB 3.1 Gen 1 header 2 x USB 2.0/1.1 headers 1 x Trusted Platform Module (TPM) header (2x10 pin, for the GC-TPM2.0 module only) 1 x serial port header 1 x Clear CMOS jumper |
| Integrated CPU Graphics | Integrated Graphics Processor |
| LAN | Realtek® GbE LAN chip (10/100/1000 Mbit) |
| Memory/Type/Bus/Max. | 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory |
| PCI Slots | 1 x PCI Express x16 slot, running at x16 (PCIEX16), 2 x PCI Express x1 slots1 x PCI Express x16 slot, running at x4, |
| Processor Support | AM4 Socket: Supports AMD Ryzenâ„¢ 5000 series/ 3rd Gen Ryzenâ„¢/ 2nd Gen Ryzenâ„¢/ 1st Gen Ryzenâ„¢/ 2nd Gen Ryzenâ„¢ with Radeonâ„¢ Vega Graphics/ 1st Gen Ryzenâ„¢ with Radeonâ„¢ Vega Graphics/ Athlonâ„¢ with Radeonâ„¢ Vega Graphics Processors |
| Raid | Support for RAID 0, RAID 1, and RAID 10 |
| RAM Type/Bus/Max. | 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory |
| Socket | AM4 Socket: Supports AMD Ryzenâ„¢ 5000 series/ 3rd Gen Ryzenâ„¢/ 2nd Gen Ryzenâ„¢/ 1st Gen Ryzenâ„¢/ 2nd Gen Ryzenâ„¢ with Radeonâ„¢ Vega Graphics/ 1st Gen Ryzenâ„¢ with Radeonâ„¢ Vega Graphics/ Athlonâ„¢ with Radeonâ„¢ Vega Graphics Processors |
| Storage Interface | 2 x M.2 connector, 6 x SATA 6Gb/s connectors |
| Warranty | 3 Years |
