Room
Scheduling Support |
|
Crestron
Scheduling App |
Crestron
Fusion software, Microsoft Exchange Server and Office 365 software, Google
Calendar and G Suite software, CollegeNET 25Live software, and Ad Astra
software (IBM Notes software is also supported through Crestron Fusion
on-premises server only) |
|
Third-Party
Apps |
Includes
support for various third-party scheduling
applications.1,2,3 |
|
Languages |
|
Crestron
Fusion |
Chinese
(Simplified), Chinese (Traditional), Danish, Dutch (Netherlands), English
(US), English (UK), French, German, Hebrew, Italian, Japanese, Korean,
Norwegian, Portuguese (Brazil), Portuguese (Portugal), Russian, Spanish,
Swedish |
|
Wired
Communications |
|
Ethernet |
100
Mbps, auto switching, auto negotiating, auto discovery, full/half duplex,
TCP/IP, UDP/IP, CIP, DHCP, SSL, TLS, SSH, SFTP (SSH File Transfer
Protocol), IEEE 802.1X, SNMP, IPv4 or IPv6, Active Directory service
authentication, HTTPS web browser setup, XiO Cloud client, IEEE 802.3at
compliant |
|
USB |
USB
2.0 host for light bar or hallway sign4 |
|
Wireless
Communications |
|
Transceiver |
IEEE
802.11a/b/g/n/ac Wi-Fi (2.4 or 5 GHz 2-way RF), static IP or dynamic IP
via DHCP |
|
Security |
64
and 128-bit WEP, WPA and WPA2-PSK with TKIP and
AES |
|
Range |
Up
to 50 ft (15 m), subject to site-specific
conditions |
|
Bluetooth
Hardware |
Crestron
Bluetooth beacon5 |
|
Touch
Screen Display |
|
Display
Type |
TFT
active matrix color LCD |
|
Size |
10.1
in. (257 mm) diagonal |
|
Aspect
Ratio |
16:10
WUXGA |
|
Resolution |
1920
x 1200 pixels |
|
Brightness |
400
nits (cd/m) |
|
Contrast |
1000:01:00 |
|
Color
Depth |
24
bit, 16.7M colors |
|
Illumination |
Edgelit
LED with auto brightness control |
|
Viewing
Angle |
80
horizontal, 80 vertical |
|
Touch
Screen |
Projected
capacitive, 5-point multitouch capable |
|
Buttons |
|
Hard
Keys |
(6)
Virtual buttons in collapsible universal tool bar, perbutton show/hide,
preconfigured with icons for Power, Home, Lights, Up, Down, and
Microphone |
|
Reset |
(1)
Pin hole on rear panel for hardware reset |
|
Audio |
|
Features |
Built-in
speakers for touch feedback and alerts |
|
Connectors |
|
LAN
PoE |
(1)
8-pin RJ45 connector, female, with 2 LED
indicators; |
|
100Base-TX
Ethernet port; |
|
PoE+
PD port; |
|
Green
and yellow LEDs indicate Ethernet port status |
|
USB |
(2)
USB Type A connectors, female; |
|
USB
2.0 host ports; |
|
For
optional room scheduling accessories |
|
Power |
|
PoE
(Power over Ethernet) |
IEEE
802.3at Type 2 compliant PoE+ PD (Powered
Device); |
|
-
Normally requests 15 W from an 802.3at Type 2 PSE with LLDP advanced power
management; |
|
-
With room scheduling and USB enabled, requests 18 W from an 802.3at Type 2
PSE with LLDP; |
|
-
Requests 30 W (PoE+ Class 4) from an 802.3at Type 2 PSE without
LLDP; |
|
-
Requests 15.4 W (PoE Class 0) from an 802.3af (or 802.3at Type
1) PSE |
|
NOTE:
Enabling the USB port requires use of an 802.3at Type 2 PoE+
PSE. |
|
Environmental |
|
Temperature |
41
to 104 F (5 to 40 C) |
|
Humidity |
10%
to 90% RH (noncondensing) |
|
Heat
Dissipation |
49
BTU/hr |
|
Construction |
|
Housing |
Plastic,
smooth black or white finish, edge-to-edge glass with black or white
surround |
|
Mounting |
Surface
mount over a 2 or 3 gang US electrical box, 2 gang European (DIN 49073)
electrical box, or 2 gang UK (BS 4662) electrical
box; |
|
Lectern
mount over a 2 in. H x 3 3/4 in. W (51 mm H x 96 mm W)
cutout; |
|
1-3/8
in. (35 mm) minimum mounting depth; |
|
Wall
mount, surface mount, and rack options available
separately |
|
Dimensions |
|
Height |
5.87
in. (149 mm) |
|
Width |
10.18
in. (259 mm) |
|
Depth |
2.28
in. (58 mm) |
|
Dimensions
do not include the mounting bracket or addon
accessories |
|
Weight |
1.61
lb (730 g) |
|
Compliance |
Regulatory
Model: M201923003 |
|
IC,
CE, FCC Part 15 Class B digital
device |
