Essentials |
|
|
Product
Collection |
Intel
NUC Kit with 12th Generation Intel Core
Processors |
|
Code
Name |
Products
formerly Wall Street Canyon |
|
Status |
Launched |
|
Launch
Date |
Q3'22 |
|
Expected
Discontinuance |
1H'25 |
|
Supported
Operating Systems |
Windows
11 Home* | Windows 11 Pro* | Windows 10 Home* | Windows 10 IoT Enterprise* | Windows 10 Pro* | Red Hat Linux* | Ubuntu 20.04
LTS* |
|
Board
Number |
NUC12WSBi7 |
|
Board
Form Factor |
UCFF
(4" x 4") |
|
Socket |
Soldered-down
BGA |
|
Internal
Drive Form Factor |
M.2
SSD |
|
#
of Internal Drives Supported |
2 |
|
TDP |
35
W |
|
DC
Input Voltage Supported |
12-20
VDC |
|
Processor
Included |
Intel
Core i7-1260P Processor (18M Cache | up to
4.70 GHz) |
|
Total
Cores |
12 |
|
Total
Threads |
16 |
|
Lithography |
Intel
7 |
|
Max
Turbo Frequency |
4.70
GHz |
|
Memory
& Storage |
|
|
Max
Memory Size (dependent on memory type) |
64
GB |
|
Memory
Types |
DDR4-3200
1.2V SODIMMs |
|
Max
# of Memory Channels |
2 |
|
Max
# of DIMMs |
2 |
|
ECC
Memory Supported
|
No |
|
Processor
Graphics |
|
|
Integrated
Graphics |
Yes |
|
Graphics
Output |
Dual
HDMI 2.0b w/HDMI CEC | Dual DP 1.4a via
Type C |
|
#
of Displays Supported |
4 |
|
Expansion
Options |
|
|
PCI
Express Revision |
Gen
4 (m.2 22x80 slot); Gen 3 (otherwise) |
|
PCI
Express Configurations |
PCIe
x4 Gen 4: M.2 22x80 (key M) PCIe x1 Gen 3: M.2 22x42 (key B) PCIe x1: M.2
22x30 (key E) |
|
M.2
Card Slot (wireless) |
22x30
(E) |
|
M.2
Card Slot (storage) |
22x80
NVMe (M); 22x42 SATA (B) |
|
I/O
Specifications |
|
|
#
of USB Ports |
4 |
|
USB
Configuration |
Front:
2x USB 3.2 Rear: 2x USB 4 (type C) | 1x
USB 3.2 | 1x USB 2.0 Internal: 1x USB 3.2
on m.2 22x42 (pins) | 2x USB 2.0
(headers) |
|
Serial
Port via Internal Header |
No |
|
Audio
(back channel + front channel) |
Front
panel: 3.5mm headphone/mic jack |
|
Integrated
LAN |
Intel
Ethernet Controller i225-V |
|
Integrated
Wireless |
Intel
Wi-Fi 6E AX211(Gig+) |
|
Integrated
Bluetooth |
Yes |
|
Additional
Headers |
Front_panel
(PWR | RST | 5V | 5Vsby | 3.3Vsby); Internal 2x2 power
connector |
|
#
of Thunderbolt Ports |
2x
Thunderbolt 4 |
|
Package
Specifications |
|
|
Chassis
Dimensions |
117
x 112 x 37 [mm] (LxWxH) |
|
Advanced
Technologies |
|
|
Intel
Optane Memory Supported |
No |
|
Intel
Virtualization Technology for Directed I/O (VT-d)
|
Yes |
|
Intel
ME Firmware Version |
16 |
|
Intel
HD Audio Technology |
Yes |
|
Intel
Virtualization Technology (VT-x) |
Yes |
|
Intel
Platform Trust Technology (Intel PTT) |
Yes |
|
Security
& Reliability |
|
|
Intel
AES New Instructions |
Yes |
