| Ports & interfaces |
|---|
| Internal | Yes |
| Connectivity technology | Wired |
| Host interface | PCI Express |
| Interface | WLAN |
| Bandwidth |
|---|
| Maximum data transfer rate | 2402 Mbit/s |
| Wireless LAN features |
|---|
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Wi-Fi | Yes |
| WLAN data transfer rates supported | 574,2402 Mbit/s |
| Antenna |
|---|
| Antenna | Yes |
| Network |
|---|
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Maximum data transfer rate | 2402 Mbit/s |
| Wi-Fi | Yes |
| Bluetooth version | 4.2 + 5.0 |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Modulation | 1024-QAM |
| WLAN data transfer rates supported | 574,2402 Mbit/s |
| Security algorithms | 64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK, WPA3 |
| Bluetooth | Yes |
| Design |
|---|
| Internal | Yes |
| Antenna | Yes |
| LED indicators | System |
| Transmitting power (CE) | 20 dBm |
| Component for | PC |
| Antenna design | External |
| System requirements |
|---|
| Windows operating systems supported | Windows 10 |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Weight & dimensions |
|---|
| Width | 78.5 mm |
| Depth | 120.8 mm |
| Height | 21 mm |
| Packaging content |
|---|
| Quick installation guide | Yes |
| Resource CD | Yes |
| Performance |
|---|
| Security algorithms | 64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK, WPA3 |
| Windows operating systems supported | Windows 10 |
| Technical details |
|---|
| Harmonized System (HS) code | 85176990 |
| Packaging data |
|---|
| Quick installation guide | Yes |
| Other features |
|---|
| Bluetooth version | 4.2 + 5.0 |
| Bluetooth | Yes |
| Harmonized System (HS) code | 85176990 |
