| Performance |
|---|
| 2.4 GHz | No |
| 5 GHz | Yes |
| Maximum data transfer rate | 200 Mbit/s |
| Spread spectrum method | OFDM |
| Frequency band | 4910 - 5970 GHz |
| VLAN support | Yes |
| Receiver sensitivity | (w/FEC) @ 200MHz Channel MCS0 = -93 dBm to MCS15 = -72 dBm (per branch);
(w/FEC) @ 40MHz Channel MCS0 = -90 dBm to MCS15 = -69 dBm (per branch). |
| Quality of Service (QoS) support | Yes |
| Networking standards | IEEE 802.1Q, IEEE 802.1p |
| Modulation | 64-QAM, BPSK |
| Channel bandwidth | 40 MHz |
| Certification | FCCID Z8H89FT0015, Industry Canada Cert 109W-0015, CE 5.4 GHz: EN 301 893 V2.1.1 5.8 GHz: EN 302 502 V2.1.1 |
| MIMO | Yes |
| Features |
|---|
| 2.4 GHz | No |
| 5 GHz | Yes |
| Maximum data transfer rate | 200 Mbit/s |
| Spread spectrum method | OFDM |
| Frequency band | 4910 - 5970 GHz |
| VLAN support | Yes |
| Receiver sensitivity | (w/FEC) @ 200MHz Channel MCS0 = -93 dBm to MCS15 = -72 dBm (per branch);
(w/FEC) @ 40MHz Channel MCS0 = -90 dBm to MCS15 = -69 dBm (per branch). |
| Quality of Service (QoS) support | Yes |
| Networking standards | IEEE 802.1Q, IEEE 802.1p |
| Modulation | 64-QAM, BPSK |
| Channel bandwidth | 40 MHz |
| MIMO | Yes |
| Security |
|---|
| Security algorithms | 128-bit AES |
| MAC address filtering | Yes |
| IP address filtering | Yes |
| Protocols |
|---|
| Management protocols | IPv4/IPv6, HTTPs, SNMPv2c, SSH, Cambium Networks CnMaestroâ„¢ |
| Supported network protocols | IPv4/IPv6, UDP, TCP, ICMP, SNMPv2c, NTP, STP, IGMP, SSH |
| IPv4 & IPv6 features | Dual stack IPv4/IPv6 |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Power |
|---|
| Power consumption (max) | 10 W |
| Power consumption (typical) | 5 W |
| Power over Ethernet (PoE) | Yes |
| AC input voltage | 10 - 30 V |
| Design |
|---|
| Placement | Pole |
| International Protection (IP) code | IP55 |
| LED indicators | LAN, Power, Signal strength |
| Product colour | White |
| Certification | FCCID Z8H89FT0015, Industry Canada Cert 109W-0015, CE 5.4 GHz: EN 301 893 V2.1.1 5.8 GHz: EN 302 502 V2.1.1 |
| Antenna |
|---|
| Antenna type | Internal |
| Polarization | Dual polarization |
| Antenna gain level (max) | 16 dBi |
| Operational conditions |
|---|
| Operating temperature (T-T) | -30 - 60 °C |
| Weight & dimensions |
|---|
| Width | 251 mm |
| Depth | 119 mm |
| Height | 124 mm |
| Weight | 500 g |
| Packaging data |
|---|
| Mounting kit | Yes |
| Packaging content |
|---|
| Mounting kit | Yes |
| Other features |
|---|
| Polarization | Dual polarization |
