| Performance |
|---|
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Auto MDI/MDI-X | Yes |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| Auto Wireless Distribution System (WDS) | Yes |
| Syslog | Yes |
| IGMP snooping | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Spread spectrum method | DSSS,OFDM |
| Frequency band | 2.4 - 2.2484, 5.15 - 5.25, 5.25 - 5.35, 5.47 - 5.725, 5.725 - 5.85 GHz |
| VLAN support | Yes |
| Reset button | Yes |
| Quality of Service (QoS) support | Yes |
| Networking standards | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11d,IEEE 802.11e,IEEE 802.11g,IEEE 802.11h,IEEE 802.11i,IEEE 802.11k,IEEE 802.11r,IEEE 802.11u,IEEE 802.11v,IEEE 802.11w,IEEE 802.1x,IEEE 802.3,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3at,IEEE 802.3u |
| Modulation | 16-QAM,64-QAM,256-QAM,BPSK,CCK,QPSK |
| Certification | FCC, CE, IC, UL, WEEE, RoHS |
| MIMO type | Multi User MIMO |
| MIMO | Yes |
| Features |
|---|
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Auto MDI/MDI-X | Yes |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Spread spectrum method | DSSS,OFDM |
| Frequency band | 2.4 - 2.2484, 5.15 - 5.25, 5.25 - 5.35, 5.47 - 5.725, 5.725 - 5.85 GHz |
| VLAN support | Yes |
| Quality of Service (QoS) support | Yes |
| Networking standards | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11d,IEEE 802.11e,IEEE 802.11g,IEEE 802.11h,IEEE 802.11i,IEEE 802.11k,IEEE 802.11r,IEEE 802.11u,IEEE 802.11v,IEEE 802.11w,IEEE 802.1x,IEEE 802.3,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3at,IEEE 802.3u |
| Modulation | 16-QAM,64-QAM,256-QAM,BPSK,CCK,QPSK |
| Cabling technology | 10/100/1000Base-T(X) |
| Bluetooth | Yes |
| Bluetooth version | 4.0 |
| MIMO type | Multi User MIMO |
| MIMO | Yes |
| Security |
|---|
| Auto Wireless Distribution System (WDS) | Yes |
| IGMP snooping | Yes |
| Security algorithms | 802.1x RADIUS,EAP-AKA,EAP-FAST,EAP-GTC,EAP-PEAP,EAP-SIM,EAP-TLS,EAP-TTLS,MSCHAPv2,PEAP,WDS,WPA-TKIP,WPA2,WPA2-AES |
| MAC address filtering | Yes |
| Protocols |
|---|
| Management protocols | SNMP v1, v2c, v3 |
| DHCP server | Yes |
| Management features |
|---|
| Syslog | Yes |
| Command-line interface (CLI) | Yes |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Cabling technology | 10/100/1000Base-T(X) |
| Power |
|---|
| Power consumption (max) | 25 W |
| Power consumption (typical) | 9 W |
| Power over Ethernet (PoE) | Yes |
| Design |
|---|
| Placement | Table, Wall |
| Reset button | Yes |
| LED indicators | Yes |
| Product colour | White |
| Cable lock slot | Yes |
| Certification | FCC, CE, IC, UL, WEEE, RoHS |
| Cable lock slot type | Kensington |
| Antenna |
|---|
| Antenna type | Internal |
| Antenna gain level (max) | 4.9 dBi |
| Antenna direction type | Omni-directional |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | 5 - 95 °C |
| Weight & dimensions |
|---|
| Width | 94 mm |
| Depth | 34 mm |
| Height | 147 mm |
| Weight | 390 g |
| Packaging data |
|---|
| Number of products included | 1 pc(s) |
| Packaging content |
|---|
| Number of products included | 1 pc(s) |
