| Performance |
|---|
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Automatic channel selection | Yes |
| Syslog | Yes |
| Maximum data transfer rate | 1733 Mbit/s |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Frequency band | 2.4 - 2.484, 5.15 - 5.85 GHz |
| Number of users | 512 user(s) |
| VLAN support | Yes |
| Transmitting power | 28 dBmW |
| Reset button | Yes |
| Quality of Service (QoS) support | Yes |
| Networking standards | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11d,IEEE 802.11e,IEEE 802.11g,IEEE 802.11h,IEEE 802.11i,IEEE 802.11k,IEEE 802.11n,IEEE 802.11r,IEEE 802.11u,IEEE 802.11v,IEEE 802.11w,IEEE 802.3af,IEEE 802.3at |
| Modulation | 16-QAM,64-QAM,256-QAM,BPSK,CCK,DSSS,OFDM,QPSK |
| Maximum indoor range | 250 m |
| Channel bandwidth | 80 MHz |
| Certification | FCC, CE, IC, UL, EN60601-1-2, UL2043 Plenum, WEEE, RoHS |
| MIMO type | Multi User MIMO |
| MIMO | Yes |
| Band steering | Yes |
| Airtime Fairness (ATF) | Yes |
| Remote Authentication Dial-In User Service (RADIUS) | Yes |
| Features |
|---|
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Automatic channel selection | Yes |
| Maximum data transfer rate | 1733 Mbit/s |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Frequency band | 2.4 - 2.484, 5.15 - 5.85 GHz |
| Number of users | 512 user(s) |
| VLAN support | Yes |
| Transmitting power | 28 dBmW |
| Quality of Service (QoS) support | Yes |
| Networking standards | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11d,IEEE 802.11e,IEEE 802.11g,IEEE 802.11h,IEEE 802.11i,IEEE 802.11k,IEEE 802.11n,IEEE 802.11r,IEEE 802.11u,IEEE 802.11v,IEEE 802.11w,IEEE 802.3af,IEEE 802.3at |
| Modulation | 16-QAM,64-QAM,256-QAM,BPSK,CCK,DSSS,OFDM,QPSK |
| Maximum indoor range | 250 m |
| Channel bandwidth | 80 MHz |
| Bluetooth | Yes |
| Maximal-Ratio Combining (MRC) | Yes |
| Dynamic Frequency Selection (DFS) | Yes |
| Data unit aggregation | A-MPDU, A-MSDU |
| Cyclic Shift Diversity (CSD) | Yes |
| Cyclic Delay Diversity (CDD) | Yes |
| MIMO type | Multi User MIMO |
| MIMO | Yes |
| Band steering | Yes |
| Airtime Fairness (ATF) | Yes |
| Maximum data transfer rate (2.4 GHz) | 400 Mbit/s |
| Maximum data transfer rate (5 GHz) | 1733 Mbit/s |
| Fit AP mode features | Hotspot 2.0 |
| Security |
|---|
| Number of SSID supported | 16 |
| Security algorithms | 802.1x RADIUS,EAP-AKA,EAP-FAST,EAP-GTC,EAP-PEAP,EAP-SIM,EAP-TLS,EAP-TTLS,MSCHAPv2,PEAP,SNMP,SNMPv2,SNMPv3,WMM,WPA-PSK,WPA-TKIP,WPA2,WPA2-AES,WPA2-Enterprise,WPA2-PSK |
| Access Control List (ACL) | Yes |
| Remote Authentication Dial-In User Service (RADIUS) | Yes |
| Protocols |
|---|
| DHCP server | Yes |
| Management features |
|---|
| Syslog | Yes |
| Ports & interfaces |
|---|
| USB 2.0 ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Power |
|---|
| Power consumption (max) | 17.2 W |
| Power over Ethernet (PoE) | Yes |
| Design |
|---|
| Placement | Ceiling, Table, Wall |
| Reset button | Yes |
| LED indicators | Yes |
| Product colour | White |
| Cable lock slot | Yes |
| Certification | FCC, CE, IC, UL, EN60601-1-2, UL2043 Plenum, WEEE, RoHS |
| Cable lock slot type | Kensington |
| Antenna |
|---|
| Antenna type | Internal |
| Polarization | Dual polarization |
| Antenna gain level (max) | 6 dBi |
| Antenna direction type | Omni-directional |
| Antenna features | Integrated antenna |
| Operational conditions |
|---|
| Operating relative humidity (H-H) | 10 - 95% |
| Operating temperature (T-T) | 0 - 50 °C |
| Software |
|---|
| Access Control List (ACL) | Yes |
| Maximal-Ratio Combining (MRC) | Yes |
| Dynamic Frequency Selection (DFS) | Yes |
| Data unit aggregation | A-MPDU, A-MSDU |
| Cyclic Shift Diversity (CSD) | Yes |
| Cyclic Delay Diversity (CDD) | Yes |
| Weight & dimensions |
|---|
| Width | 180 mm |
| Depth | 42 mm |
| Height | 180 mm |
| Weight | 558 g |
| Packaging data |
|---|
| Number of products included | 1 pc(s) |
| Other features |
|---|
| Firewall security | Layer-2, Layer-3, DNS ACLs, DoS protection |
| Polarization | Dual polarization |
| Packaging content |
|---|
| Number of products included | 1 pc(s) |
