| Network |
|---|
| IGMP snooping | Yes |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1p, IEEE 802.1w, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x |
| Full duplex | Yes |
| Number of VLANs | 1024 |
| VLAN support | Yes |
| Port mirroring | Yes |
| Link aggregation | Yes |
| Flow control support | Yes |
| Broadcast storm control | Yes |
| Auto MDI/MDI-X | Yes |
| 10G support | No |
| Auto-negotiation | Yes |
| Ethernet Ring Protection Switching (ERPS) | Yes |
| Virtual LAN features | Tagged VLAN, Protocol-based VLAN, Port-based VLAN |
| Virtual LAN features |
|---|
| Number of VLANs | 1024 |
| VLAN support | Yes |
| Virtual LAN features | Tagged VLAN, Protocol-based VLAN, Port-based VLAN |
| Data transmission |
|---|
| Number of VLANs | 1024 |
| Jumbo frames | 9216 |
| MAC address table | 8192 entries |
| Switching capacity | 24 Gbit/s |
| Store-and-forward | Yes |
| Number of queues | 8 |
| Jumbo frames support | Yes |
| Packet buffer memory | 4 MB |
| Forwarding rate | 17.85 Mpps |
| Performance |
|---|
| Packet buffer memory | 4 MB |
| Auto-negotiation | Yes |
| Internal memory | 128 MB |
| Flash memory | 16 MB |
| Harmonized System (HS) code | 85176990 |
| Management features |
|---|
| Switch layer | L2 |
| Switch type | Managed |
| Quality of Service (QoS) support | Yes |
| Ports & interfaces |
|---|
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Installed SFP modules quantity | 4 |
| Gigabit Ethernet (copper) ports quantity | 8 |
| Security |
|---|
| IGMP snooping | Yes |
| DHCP features | DHCPv6 client, DHCP server, DHCP snooping, DHCP client |
| Design |
|---|
| International Protection (IP) code | IP30 |
| Product colour | Black, Lilac |
| LED indicators | Link, PoE, Power, Ring, Status |
| Certification | RoHS |
| Technical details |
|---|
| Harmonized System (HS) code | 85176990 |
| Power |
|---|
| AC input frequency | 47/63 Hz |
| Redundant power supply (RPS) support | Yes |
| Power over Ethernet (PoE) |
|---|
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet plus (PoE+) ports quantity | 8 |
| Total Power over Ethernet (PoE) budget | 480 W |
| Operational conditions |
|---|
| Operating temperature (T-T) | -40 - 75 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Weight & dimensions |
|---|
| Width | 77 mm |
| Depth | 128 mm |
| Height | 154 mm |
| Weight | 1.41 kg |
